AH Mini Cat Air Hoist 6.5' Lift-Capacitie 500 lb. AH500M Air Powered Hoist HARRINGTON

Product Overview

The AH500M-6.5 HARRINGTON AH Mini Cat Air Hoist is the ultimate solution for all your lifting needs. Designed with precision and attention to detail, this lightweight and compact hoist is ideal for on-site jobs, workstations, and assembly line applications. With a lifting capacity ranging from 500 lb., this hoist is perfect for a wide range of lifting tasks.Equipped with a maximum lift of 6.5 feet, the AH500M-6.5 HARRINGTON AH Mini Cat Air Hoist ensures easy and efficient lifting in any situation. Whether you need to lift heavy machinery or transport materials to higher levels, this hoist will provide the power and versatility you need to get the job done.One of the key features of this hoist is its small body design, which allows for easy maneuverability in tight spaces. No matter how cramped or confined the working area is, this hoist will ensure smooth and hassle-free operation. You can easily navigate through narrow passages or maneuver around obstacles without any difficulties.Reliability is another crucial factor when it comes to lifting equipment, and the AH500M-6.5 HARRINGTON AH Mini Cat Air Hoist does not disappoint. Built with durability in mind, this hoist is designed to withstand the toughest of conditions and provide efficient operation. You can rely on this hoist to perform flawlessly, day in and day out, and complete your lifting tasks with ease.Experience the convenience and efficiency of the AH500M-6.5 HARRINGTON AH Mini Cat Air Hoist and revolutionize your lifting tasks today. Whether you are working on a construction site or in a factory, this hoist will prove to be an invaluable tool that saves you time and effort. Don't settle for less when it comes to your lifting needs. Choose the AH500M-6.5 HARRINGTON AH Mini Cat Air Hoist for unmatched performance and reliability.

Product Specifications

.

Part Number:

AH500M-6.5

Color:

Yellow

Hoist Lift:

6 1/2 ft

Product:

Air Chain Hoist, 500 lb. Cap., 6.5 ft. Lft=Hoist Mount=Hook Mounted-No Trolley

Lift Speed:

29 fpm

Housing Width:

4 in

Manufacturers Warranty Length:

1 yr

Housing Length:

9 11/16 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

7 3/16 in

Body Depth:

11 5/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

11 5/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

6 1/2 ft

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

33 in

Load Capacity:

500 lb

Minimum Between Hooks:

33 in

Standards:

ANSI/ASME B30.17

Item:

Air Chain Hoist

Reeving:

1

Trolley Configuration:

Hook Mounted-No Trolley

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Not Included

Overload Protection Included:

Yes

Brake Type:

Self-Adjusting

Chain Grade:

Grade 80

Included Components:

Chain Container

Fixed Lift Speed:

53 fpm

Chain Finish:

Nickel Plated

Controls:

=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Headroom:

33 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Cast Aluminum

Programmable:

Non-Programmable
