AH Mini Cat Air Hoist 13' Lift-Capacitie 250 lb. AH250M Air Powered Hoist HARRINGTON

Product Overview

The AH250M-13 HARRINGTON AH Mini Cat Air Hoist is the ultimate lifting solution for all your on-site jobs, workstations, and assembly line applications. With a lifting capacity ranging from 250 lb. and a 13' lift, this compact and lightweight hoist is perfect for any task.What sets this air hoist apart from others is its small body design, which allows for easy maneuverability and convenience. No matter the size or weight of your load, this hoist is designed to handle it with ease. With the AH250M-13, you can trust in the reliability and durability of Harrington's AH Mini Cat air chain hoists.Built to last, this air hoist is constructed with high-quality materials that can withstand the toughest job sites and applications. Whether you are lifting heavy machinery or delicate equipment, this hoist delivers exceptional performance every time.Featuring a user-friendly design, the AH250M-13 is incredibly easy to operate, making it suitable for both novice and experienced operators. Its ergonomic handle provides a comfortable grip, allowing for precise and controlled lifting.Safety is of the utmost importance, which is why this hoist is equipped with numerous safety features. From the automatic brake system that ensures load control to the overload protection device that prevents excessive lifting, you can have peace of mind knowing that you are using a hoist that prioritizes safety.When it comes to lifting, you need a hoist that not only gets the job done but also exceeds your expectations. The AH250M-13 HARRINGTON AH Mini Cat Air Hoist is the perfect solution. Its power, versatility, and reliability make it an indispensable tool for any workplace. So why wait? Get yours today and discover the difference it can make in your work.

Product Specifications

.

Part Number:

AH250M-13

Color:

Yellow

Hoist Lift:

41 fpm

Product:

Air Chain Hoist, 250 lb. Cap., 13 ft. Lift=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Nickle Plated Load Chain

Lift Speed:

13 ft

Housing Width:

4 in

Manufacturers Warranty Length:

1 yr

Housing Length:

11 5/16 in

For Minimum Beam Flange Width:

Not Applicable

For Minimum Beam Flange Height:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Height:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

4 in

Body Depth:

11 5/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

11 5/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

13 ft

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

33 in

Load Capacity:

250 lb

Minimum Between Hooks:

45 in

Standards:

ANSI/ASME B30.17

Item:

Air Chain Hoist

Reeving:

1

Trolley Configuration:

Hook Mounted-No Trolley

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Not Included

Overload Protection Included:

Yes

Brake Type:

Self-Adjusting

Chain Grade:

Grade 80

Included Components:

Chain Container

Fixed Lift Speed:

41 fpm

Chain Finish:

Nickel Plated

Controls:

Pendant=Mount Type=Hook Mounted-No Trolley

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Headroom:

45 in

Includes Brake:

Brake Included

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Body Finish:

Painted

Number of Load Chains:

1

Body Material:

Cast Aluminum

Programmable:

Non-Programmable
