TNER Entertainment Electric Chain Hoist 10' Lift-Capacity 2 Tons TNER020L Electric Chain Hoist HARRINGTON

Product Overview

The TNER020L-10 HARRINGTON TNER Entertainment Electric Chain Hoist redefines efficiency in the handling of stage and theatrical equipment. Designed specifically for the stringent demands of the entertainment industry, this electric hoist combines advanced technology with robust construction, providing a reliable 10-foot lift capacity of up to 2 tons.

Crafted from durable materials, the TNER020L-10 is engineered to endure the rigors of daily use, ensuring it remains a steadfast ally in your production efforts. Its sophisticated features offer remarkable precision in lifting and moving heavy equipment, enabling creators to navigate the challenges of staging with confidence. This hoist is not just a tool; it's an essential companion for various applications, whether it‚ positioning scenery for a play, installing lighting for a concert, or transitioning elements in a dance performance.

Efficiency is key in any production, and the TNER020L-10 excels by eliminating the physical strain of manual labor. The electric chain hoist simplifies the lifting process, allowing users to save valuable time and energy while ensuring safety and smooth operation. Its intuitive controls make it accessible for everyone, even those unfamiliar with rigging, ensuring that your team can focus solely on delivering an exceptional experience to your audience.

Count on the TNER020L-10 HARRINGTON TNER Entertainment Electric Chain Hoist to elevate your productions with its exceptional reliability and powerful lifting capabilities. Designed to enhance both safety and functionality, this hoist enables smooth and seamless transitions, empowering you to achieve creative visions without compromise. Elevate your standards and invest in a hoist that guarantees peak performance, setting a new benchmark in entertainment production.

Product Specifications

.

Part Number:

TNER020L-10

Color:

Black

Hoist Lift:

10 ft

Product:

Electric Theatre Chain Hoist, 4,000 lb, 10 ft, Hook Mounted-No Trolley, Black=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Plug and Play Voltage Changer

Lift Speed:

8 fpm

Housing Width:

8 13/16 in

Manufacturers Warranty Length:

1 yr, 5 yr Brake Warranty

Housing Depth:

22 13/16 in

Housing Length:

20 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

8 13/16 in

Body Depth:

15 in

For Minimum Beam Height:

Not Applicable

Body Length:

20 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

2 1/2 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 1/2 in

Minimum Retracted Length:

22 13/16 in

Load Capacity:

4,000 lb

Minimum Between Hooks:

22 13/16 in

Motor HP:

1.3 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, BGV-D8, EC EMC Directive 2004/108/EC, EC Low Voltage Directive 2006/95/EC, EC Machinery Directive 2006/42/EC, EN14492-2, EN60204-1, EN60204-32, EN61000-6-2, EN61000-6-4, EN818-7, ENISO 12100, ENISO 13850, FEM 9.511, FEM 9.68

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Grease

Reeving:

1

Thermal Protection:

Yes

Amps @ Low Volts:

5.6 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Easy Lift Handles, Non-Drip, Grease-Packed Gearbox, Plug and Play Voltage Changer, Quiet Load Sheave, Self-Adjusting Pull-Rotor Motor Brake, Standard Overload Protection, Unique Chain Guide

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Safety Latch Hook

Fixed Lift Speed:

8 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

Not Applicable

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

150

Duty Classification:

H3

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

22 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

4,000 lb

Current at Minimum Voltage:

5.6 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

2.8 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
