TNER Entertainment Electric Chain Hoist 60' Lift-Capacity 1/2 Tons TNER005L Electric Chain Hoist HARRINGTON

Product Overview

Upgrade your stage and theatrical equipment with the reliable and powerful TNER005L-60 HARRINGTON TNER Entertainment Electric Chain Hoist. This cutting-edge hoist is designed to handle all your entertainment needs, ensuring smooth and seamless operations. With a lifting capacity ranging from 1/2 tons and a generous 60' lift, this hoist offers exceptional performance and versatility.The TNER005L-60 HARRINGTON TNER Entertainment Electric Chain Hoist is equipped with advanced technology that guarantees secure and efficient handling of heavy lighting, sound, and set pieces. No need to worry about the weight and size of your equipment, as this hoist can handle it all with ease. It is specially designed to meet the demands of the entertainment industry, providing you with the confidence you need for your productions.The KREWMATE entertainment chain hoist is known for its reliability and durability. It is built to last and can withstand the rigors of daily use. You can trust this hoist to handle your valuable equipment safely and efficiently, allowing you to focus on delivering an unforgettable experience to your audience.In addition to its exceptional performance, the TNER005L-60 HARRINGTON TNER Entertainment Electric Chain Hoist is also designed with convenience in mind. It features a user-friendly control panel that allows for easy operation and precise control. The hoist is also compact and easy to transport, making it suitable for different venues and applications.With the TNER005L-60 HARRINGTON TNER Entertainment Electric Chain Hoist, you can elevate your productions to new heights. Whether you are organizing a concert, a theater performance, or any other entertainment event, this hoist will help you deliver a flawless show every time. Don't miss out on the opportunity to enhance your stage and theatrical equipment. Shop now and experience the difference that the TNER005L-60 HARRINGTON TNER Entertainment Electric Chain Hoist can make to your productions.

Product Specifications

.

Part Number:

TNER005L-60

Color:

Black

Hoist Lift:

60 ft

Product:

Electric Theatre Chain Hoist, 1,000 lb, 60 ft, Hook Mounted-No Trolley, Black=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container, Plug and Play Voltage Changer, (Pendant Control is not Included)

Lift Speed:

16 fpm

Housing Width:

7 7/8 in

Manufacturers Warranty Length:

1 yr, 5 yr Brake Warranty

Housing Depth:

13 13/16 in

Housing Length:

18 11/16 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

7 7/8 in

Body Depth:

14 3/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

18 11/16 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

60 ft

Controller Cord Length:

2 1/2 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

29/32 in

Minimum Retracted Length:

13 3/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

13 13/16 in

Motor HP:

0.65 hp

Phase:

3

Standards:

ASME B30.16, ASME HST-1M, BGV-D8, EC EMC Directive 2004/108/EC, EC Low Voltage Directive 2006/95/EC, EC Machinery Directive 2006/42/EC, EN14492-2, EN60204-1, EN60204-32, EN61000-6-2, EN61000-6-4, EN818-7, ENISO 12100, ENISO 13850, FEM 9.511, FEM 9.68

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Grease

Reeving:

1

Thermal Protection:

Yes

Amps @ Low Volts:

3.7 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Easy Lift Handles, Non-Drip, Grease-Packed Gearbox, Plug and Play Voltage Changer, Quiet Load Sheave, Self-Adjusting Pull-Rotor Motor Brake, Standard Overload Protection, Unique Chain Guide

Material:

Not Applicable

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Safety Latch Hook

Fixed Lift Speed:

16 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

Not Applicable

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

150

Duty Classification:

H3

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

13 3/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.7 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

1.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
