Custom Field
Part Number TCL6000P2-10
Color Yellow
Hoist Lift 5.2 fpm
Product Air Chain Hoist, Pendant, 10,000 lb., 10 ft=Hoist Mount=Hook Mounted-No Trolley
Includes Chain Container
Lift Speed 10 ft
Housing Width 13 45/64 in
Manufacturers Warranty Length 1 yr
Housing Length 22 in
For Minimum Beam Flange Width Not Applicable
For Minimum Beam Flange Height Not Applicable
For Maximum Beam Flange Width Not Applicable
For Maximum Beam Flange Height Not Applicable
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 14 19/32 in
Body Depth 22 11/16 in
For Minimum Beam Height Not Applicable
Body Length 22 in
Minimum Radius Curve Not Applicable
Maximum Lifting Length 10 ft
Lifting Hook Opening Width 1 11/16 in
Minimum Retracted Length 30 5/16 in
Load Capacity 10,000 lb
Minimum Between Hooks 31 in
Standards ASME B30.16, ASME HST-5, EU ATEX
Item Air Chain Hoist
Reeving 2
Trolley Configuration Hook Mounted-No Trolley
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Not Included
Overload Protection Included Yes
Brake Type Disc
Chain Grade Grade 80
Included Components Chain Container
Fixed Lift Speed 5.2 fpm
Chain Finish Nickel Plated
Controls Pendant=Mount Type=Hook Mounted-No Trolley
Maximum Pulling Capacity Not Applicable
Number of Reeves 2
Headroom 30 3/10 in
Includes Brake Brake Included
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 12,000 lb
Body Finish Powder Coated
Number of Load Chains 2
Body Material Cast Aluminum
Programmable Non-Programmable
