SKU:
TCL6000C2-10
Condition:
New
Availability:
In stock
Weight:
293.00 LBS
Shipping:
Free Shipping
Part Number:
TCL6000C2-10
Color:
Yellow
Hoist Lift:
10 ft
Product:
Air Chain Hoist, Pull Cord, 10,000 lb, 10ft=Hoist Mount=Hook Mounted-No Trolley
Lift Speed:
5.2 fpm
Housing Width:
13 45/64 in
Manufacturers Warranty Length:
1 yr
Housing Length:
22 in
For Minimum Beam Flange Width:
Not Applicable
For Minimum Beam Flange Height:
Not Applicable
For Maximum Beam Flange Width:
Not Applicable
For Maximum Beam Flange Height:
Not Applicable
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
14 19/32 in
Body Depth:
22 11/16 in
For Minimum Beam Height:
Not Applicable
Body Length:
22 11/16 in
Minimum Radius Curve:
Not Applicable
Maximum Lifting Length:
10 ft
Lifting Hook Opening Width:
1 11/16 in
Minimum Retracted Length:
30 5/16 in
Load Capacity:
10,000 lb
Minimum Between Hooks:
31 in
Standards:
ASME B30.16, ASME HST-5, EU ATEX
Item:
Air Chain Hoist
Reeving:
2
Finish:
Powder Coated
Trolley Configuration:
Hook Mounted-No Trolley
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Not Included
Overload Protection Included:
Yes
Brake Type:
Disc
Chain Grade:
Grade 80
Included Components:
Chain Container
Fixed Lift Speed:
5.2 fpm
Chain Finish:
Nickel Plated
Controls:
=Mount Type=Hook Mounted-No Trolley
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
2
Headroom:
30 3/10 in
Includes Brake:
Brake Included
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
12,000 lb
Body Finish:
Powder Coated
Number of Load Chains:
2
Body Material:
Cast Aluminum
Programmable:
Non-Programmable
