SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 3 Tons SNERP030C Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your lifting operations with the SNERP030C-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley. This high-quality hoist is designed for extreme duty applications, offering impressive strength and reliability. With a lifting capacity ranging from 3 Tons, it is suitable for a wide range of heavy lifting needs.The 10-foot lift allows for efficient vertical movement, ensuring your tasks are completed with ease. Whether you need to lift heavy machinery, construction materials, or other substantial objects, this electric chain hoist is up to the challenge.Equipped with a single-phase power system, this electric chain hoist delivers exceptional performance while minimizing energy consumption. This means you can rely on its power and efficiency while also reducing your energy costs.The push trolley feature adds convenience and flexibility to your operations. Easily move the hoist along the beam to position it exactly where you need it. This saves time and effort, allowing you to focus on the task at hand.The SNERP030C-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley is built to last. Its durable construction and robust motor ensure it can withstand heavy use in demanding environments. This hoist is designed for extreme duty applications, providing the strength and reliability you need to tackle even the toughest lifting tasks.Choose the SNERP030C-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley to enhance your productivity and meet your toughest lifting requirements. Whether you're working in a warehouse, construction site, or industrial facility, this hoist is the ideal solution for efficiently and safely lifting heavy loads.Invest in the SNERP030C-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley and experience the benefits of a reliable and powerful lifting solution. Trust in its performance, durability, and flexibility to enhance your operations and take your lifting capabilities to new heights.

Product Specifications

.

Part Number:

SNERP030C-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 6,000 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

Chain Container,, Push Trolley

Lift Speed:

3.5 fpm

Housing Width:

16 1/2 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

8 5/16 in

Housing Length:

26 7/8 in

For Minimum Beam Flange Width:

3 1/4 in

For Maximum Beam Flange Width:

6 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 1/2 in

Body Depth:

8 5/16 in

For Minimum Beam Height:

6 in

Body Length:

26 7/8 in

Minimum Radius Curve:

66 29/32 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

5 4/5 in

Lifting Hook Opening Width:

1 11/16 in

Minimum Retracted Length:

29 5/16 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

28 7/8 in

Motor HP:

1.2 hp

Phase:

1

Standards:

ANSI/ASME B30.16, ASME HST-1M

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Option

Control Cord:

6 ft

Amps @ Low Volts:

23.9 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

3.5 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

1 1/4 hp

Headroom:

28 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

23.9 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

0

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
