SNERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1 Tons SNERP010S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The SNERP010S-15 HARRINGTON SNERP Electric Chain Hoist with Push Trolley is the perfect solution for all your heavy-duty lifting tasks. Designed with a robust build and advanced features, this single-phase hoist delivers exceptional performance and reliability. Whether you work in manufacturing, construction, or any industry that demands superior strength and durability, this electric chain hoist is built to handle even the toughest lifting tasks with ease.With a lift capacity of 15 feet and a range of 1 Tons, the SNERP010S-15 offers unmatched power and versatility. It is ideal for lifting heavy loads and ensuring precise positioning with smoothness. The push trolley feature adds convenience, allowing for easy maneuverability and effortless transportation of your loads.Harrington is a name trusted in the industry, renowned for its unmatched quality and reliability. The SNERP010S-15 is a testament to Harrington's commitment to delivering products that exceed expectations. Its robust build ensures that it can withstand the demands of any heavy-duty application, providing a reliable solution that will last for years.Whether you need to lift equipment, materials, or any other heavy loads, the SNERP010S-15 is designed to make your job easier. Its advanced features and superior power allow for efficient and effortless lifting, saving you valuable time and energy. You can trust that your lifting operations will be smooth, safe, and efficient with this electric chain hoist.Experience the power and reliability of the SNERP010S-15 HARRINGTON SNERP Electric Chain Hoist with Push Trolley. Choose this hoist for all your heavy-duty lifting needs and rely on Harrington's commitment to delivering superior quality and performance. Invest in a product that will truly exceed your expectations and provide you with peace of mind for years to come.

Product Specifications

.

Part Number:

SNERP010S-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 2,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

Chain Container,, Push Trolley

Lift Speed:

14 fpm

Housing Width:

16 1/2 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

8 5/16 in

Housing Length:

26 7/8 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 1/2 in

Body Depth:

8 5/16 in

For Minimum Beam Height:

4 3/16 in

Body Length:

26 7/8 in

Minimum Radius Curve:

51 3/16 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

4 1/5 in

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

19 1/2 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

17 11/16 in

Motor HP:

1.2 hp

Phase:

1

Standards:

ANSI/ASME B30.16, ASME HST-1M

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Option

Control Cord:

11 ft

Amps @ Low Volts:

23.9 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

17 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

23.9 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

0

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
