SNERP010S-10 HARRINGTON Electric Chain Hoist
SNERP010S-10
video
SNERP010S-10 HARRINGTON Electric Chain Hoist
SNERP010S-10

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons SNERP010S Electric Chain Hoist with Push Trolley HARRINGTON

Write a Review
$5,881.11
$5,045.36
(You save $835.75 )
SKU: SNERP010S-10-10
Condition: New
Availability: In stock
Weight: 179.00 LBS
Shipping: Free Shipping
Part Number: SNERP010S-10
Color: Yellow
Hoist Lift: 10 ft
Product: Electric Chain Hoist, 2,000 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley
Includes: Chain Container,, Push Trolley
Lift Speed: 14 fpm
Housing Width: 16 1/2 in
Manufacturers Warranty Length: 1 yr
Housing Depth: 8 5/16 in
Housing Length: 26 7/8 in
For Minimum Beam Flange Width: 2 1/4 in
For Maximum Beam Flange Width: 5 in
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 16 1/2 in
Body Depth: 8 5/16 in
For Minimum Beam Height: 4 3/16 in
Body Length: 26 7/8 in
Minimum Radius Curve: 51 3/16 in
Maximum Lifting Length: 10 ft
Controller Cord Length: 6 ft
Trolley Wheel Diameter: 4 1/5 in
Lifting Hook Opening Width: 1 3/16 in
Minimum Retracted Length: 19 1/2 in
Load Capacity: 2,000 lb
Minimum Between Hooks: 17 11/16 in
Motor HP: 1.2 hp
Phase: 1
Standards: ANSI/ASME B30.16, ASME HST-1M
Voltage: 115/230V
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 1
Thermal Protection: Option
Control Cord: 6 ft
Amps @ Low Volts: 23.9 A
Number of Speeds: 1
Trolley Configuration: Push Trolley
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material: Die Cast Aluminum
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: Pull Rotor
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed: 14 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 1 1/4 hp
Headroom: 17 19/32 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 2,000 lb
Current at Minimum Voltage: 23.9 A
Trolley Wheel Material: Steel
Current at Maximum Voltage: 0
Body Finish: Enamel
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Adding to cart… The item has been added
SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons SNERP010S Electric Chain Hoist with Push Trolley HARRINGTON

SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons SNERP010S Electric Chain Hoist with Push Trolley HARRINGTON

$5,881.11
$5,045.36
(You save $835.75 )

SNERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons SNERP010S Electric Chain Hoist with Push Trolley HARRINGTON

$5,881.11
$5,045.36
(You save $835.75 )
Description

Experience the unparalleled strength and reliability of the SNERP010S-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley, specifically engineered for extreme-duty lifting applications. With its impressive lift capacity of 10 feet and capability to handle loads up to 1 ton, this electric chain hoist is the ultimate solution for even the most demanding lifting tasks.

Designed for maximum durability, the SNERP010S-10 is constructed from robust materials that can endure extensive use in tough working environments. This hoist is not only built to last but is also crafted to provide dependable and efficient performance, ensuring that your operations run smoothly. Say goodbye to interruptions due to equipment failure as you invest in exceptional lifting power.

  • Heavy-Duty Lifting Capacity: Capable of handling loads up to 1 ton, perfect for industrial lifting tasks.
  • 10 Feet Lift Height: Designed for versatility, this hoist can elevate loads effectively in various operational settings.
  • Push Trolley Mechanism: Enables precise control and seamless maneuverability for improved operational efficiency.
  • Durable Construction: Built with robust materials to withstand rigorous applications and ensure a long lifespan.
  • Noise-Reduction Design: Operates quietly, making it ideal for environments where noise levels must be minimal.
  • Easy Installation: Straightforward setup makes this hoist a go-to for quick deployment in any workspace.
  • Safety Features: Equipped with emergency stop features and overload protection to enhance operational safety.

Whether you are in construction, manufacturing, or any sector that requires reliable heavy lifting, the SNERP010S-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley stands as your ideal ally. This tool not only promises high performance but also boosts efficiency, allowing you to revamp your workflows and increase organizational productivity.

Invest in the SNERP010S-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley today and revolutionize your lifting processes. Featuring exceptional functionality and robust build quality, this hoist makes tackling rigorous lifting applications not just achievable but effortless. Seize the opportunity to enhance your operations and drive productivity forward. Place your order for the SNERP010S-10 HARRINGTON SNERP Electric Chain Hoist with Push Trolley now!
