SKU:
SNERP005S-15-15
Condition:
New
Availability:
In stock
Weight:
95.90 LBS
Shipping:
Free Shipping
Part Number:
SNERP005S-15
Color:
Yellow
Hoist Lift:
15 ft
Product:
Electric Chain Hoist, 1,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley
Includes:
Chain Container,, Push Trolley
Lift Speed:
15 fpm
Housing Width:
13 13/16 in
Manufacturers Warranty Length:
1 yr
Housing Depth:
7 1/2 in
Housing Length:
23 1/4 in
For Minimum Beam Flange Width:
2 1/4 in
For Maximum Beam Flange Width:
5 in
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
13 13/16 in
Body Depth:
7 1/2 in
For Minimum Beam Height:
3 3/16 in
Body Length:
23 1/4 in
Minimum Radius Curve:
43 5/16 in
Maximum Lifting Length:
15 ft
Controller Cord Length:
11 ft
Trolley Wheel Diameter:
3 1/5 in
Lifting Hook Opening Width:
29/32 in
Minimum Retracted Length:
16 3/32 in
Load Capacity:
1,000 lb
Minimum Between Hooks:
15 3/8 in
Motor HP:
0.6 hp
Phase:
1
Standards:
ANSI/ASME B30.16, ASME HST-1M
Voltage:
115/230V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Oil Bath
Reeving:
1
Thermal Protection:
Option
Control:
110v
Control Cord:
11 ft
Amps @ Low Volts:
16.9 A
Number of Speeds:
1
Trolley Configuration:
Push Trolley
Trolley Speed:
Not Applicable
Features:
Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
Yes
Brake Type:
Pull Rotor
Chain Grade:
Grade 80
Maximum Lift Speed:
Not Applicable
Included Components:
Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed:
15 fpm
Clutch Type:
Friction Clutch
Minimum Lift Speed:
Not Applicable
Pendant IP Rating:
IP65
Chain Finish:
Nickel Plated
Controls:
Push Button Pendant=Mount Type=Push Trolley
Starts and Stops per Hour:
360
Duty Classification:
H4
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
5/8 hp
Headroom:
15 5/16 in
Includes Brake:
Brake Included
For Outdoor Use:
Yes
Hoist IP Rating:
IP55
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
1,000 lb
Current at Minimum Voltage:
16.9 A
Trolley Wheel Material:
Steel
Current at Maximum Voltage:
8.5 A
Body Finish:
Enamel
Number of Load Chains:
1
Body Material:
Aluminum
Trolley IP Rating:
Not Applicable
Programmable:
Non-Programmable
