SKU:
SNERP005L-15-15
Condition:
New
Availability:
In stock
Weight:
324.90 LBS
Shipping:
Free Shipping
product:
Electric Chain Hoist, 1,000 lb, 15 ft, Push Trolley
Color:
Yellow
Hoist Lift:
15 ft
Hoist Mount:
Push Trolley
Includes:
Chain Container,, Push Trolley
Lift Speed:
7 fpm
Housing Width:
13 in
Manufacturers Warranty Length:
1 yr
Housing Length:
22 1/4 in
Housing Depth:
6 5/8 in
Minimum Retracted Length:
15 13/32 in
Minimum Radius Curve:
43 5/16 in
For Maximum Beam Height:
Not Applicable
Trolley Wheel Diameter:
3 1/5 in
Lifting Hook Opening Width:
29/32 in
Maximum Lifting Length:
15 ft
Controller Cord Length:
11 ft
For Max Beam Flange Width:
5 in
Body Depth:
6 5/8 in
Body Length:
22 1/4 in
For Minimum Beam Height:
3 3/16 in
Body Width:
13 in
For Min Beam Flange Width:
2 1/4 in
Electric Hoist Item:
Chain Hoist
Load Capacity:
1,000 lb
Min Between Hooks:
14 5/8 in
Motor HP:
0.34 hp
Phase:
1
Standards:
ANSI/ASME B30.16, ASME HST-1M
Voltage:
115/230V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Oil Bath
Control Cord:
11 ft
Reeving:
1
Clutch:
Friction Clutch
Trolley Configuration:
Push Trolley
Thermal Protection:
Option
Amps @ Low Volts:
7.7 A
Brake:
Pull-Rotor
Finish:
Electrostatic Enamel
Number of Speeds:
1
Fits Beam Flange W:
2-1/4 in to 5 in
Classification:
H4
Control:
110v
Item:
Electric Chain Hoist
Trolley Speed:
Not Applicable
Features:
Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material:
Die Cast Aluminum
Trolley Wheel Material:
Steel
Chain Finish:
Nickel Plated
Body Finish:
Enamel
Duty Classification:
H4
Controls:
Push Button Pendant
Motor Horsepower:
3/8 hp
Includes Clutch:
Clutch Included
Maximum Lifting Capacity:
1,000 lb
