Part Number
Part Number SNER030C-15
Color Yellow
Hoist Lift 15 ft
Product Electric Chain Hoist, 6,000 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley
Includes Chain Container
Lift Speed 3.5 fpm
Housing Width 13 3/16 in
Manufacturers Warranty Length 1 yr
Housing Depth 8 5/16 in
Housing Length 29 1/2 in
For Minimum Beam Flange Width Not Applicable
For Maximum Beam Flange Width Not Applicable
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 13 3/16 in
Body Depth 8 5/16 in
For Minimum Beam Height Not Applicable
Body Length 29 1/2 in
Minimum Radius Curve Not Applicable
Maximum Lifting Length 15 ft
Controller Cord Length 11 ft
Trolley Wheel Diameter Not Applicable
Lifting Hook Opening Width 1 11/16 in
Minimum Retracted Length 26 29/32 in
Load Capacity 6,000 lb
Minimum Between Hooks 29 1/2 in
Motor HP 1.2 hp
Phase 1
Standards ASME B30.16, ASME HST-1, NFPA 70
Voltage 115/230V
Fits Brand Harrington Hoists Inc
Lubrication Oil Bath
Reeving 2
Thermal Protection No
Control Cord 11 ft
Amps @ Low Volts 23.9 A
Number of Speeds 1
Trolley Configuration Hook Mounted
Trolley Speed Not Applicable
Features Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material Die Cast Aluminum
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type Pull Rotor
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed 3.5 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls =Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour 360
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 2
Motor Horsepower 1 1/4 hp
Headroom 29 1/2 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 6,000 lb
Current at Minimum Voltage 23.9 A
Trolley Wheel Material Not Applicable
Current at Maximum Voltage 0
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating Not Applicable
Programmable Non-Programmable
