SNER Electric Chain Hoist 10' Lift-Capacity 3 Tons SNER030C Electric Chain Hoist HARRINGTON

Product Overview

The SNER030C-10 HARRINGTON SNER Electric Chain Hoist is a heavy-duty liftingsolution that exceeds expectations. With a capacity of 3 tons, this hoistcan effortlessly handle extreme loads in a wide range of industrial applications.What sets the SNER030C-10 HARRINGTON SNER Electric Chain Hoist apart is itscompatibility with single-phase power. This versatility allows for easy lifting,lowering, and positioning of heavy objects in various industrial settings.Safety is paramount, and this hoist is designed with advanced safety mechanismsto ensure efficient and accident-free lifting operations. Providing exceptionalperformance while prioritizing worker well-being, the SNER030C-10 HARRINGTON SNERElectric Chain Hoist can be trusted for all your lifting needs.Durability is a key feature of this hoist, as it is built to withstand the toughestconditions. The robust construction ensures that it can handle heavy usage withoutcompromising reliability, making it a sound investment for your business.The SNER030C-10 HARRINGTON SNER Electric Chain Hoist incorporates cutting-edgetechnology that delivers the power and precision required for heavy-duty lifting. Thisinnovative hoist is a step above the rest, ensuring your operations benefit from thelatest advancements.Choose the SNER030C-10 HARRINGTON SNER Electric Chain Hoist if you need a reliableand powerful solution for your heavy-duty applications. Its exceptional performance,durability, and innovative features make it the perfect lifting solution for anyindustrial setting.Invest in the power and precision of the SNER030C-10 HARRINGTON SNER Electric ChainHoist today. Experience the difference it can make in your lifting operations and haveconfidence in its ability to handle your heavy-duty needs. Don't settle for anythingless than the best - choose the SNER030C-10 HARRINGTON SNER Electric Chain Hoist.

Product Specifications

.

Part Number:

SNER030C-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 6,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

3.5 fpm

Housing Width:

13 3/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

8 5/16 in

Housing Length:

29 1/2 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 3/16 in

Body Depth:

8 5/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

29 1/2 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 11/16 in

Minimum Retracted Length:

26 29/32 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

29 1/2 in

Motor HP:

1.2 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

No

Control Cord:

6 ft

Amps @ Low Volts:

23.9 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

3.5 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

1 1/4 hp

Headroom:

29 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

23.9 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

0

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
