Product Overview
The SNER020L-20 HARRINGTON SNER Electric Chain Hoist is the ultimate powerhouse for all your heavy-duty lifting needs. Designed to handle extreme loads using single-phase power, this hoist will exceed your expectations in terms of power and reliability.With its 20' lift capability, you can easily move your materials to the desired height without any hassle. No more struggling with manual lifting or depending on multiple people to get the job done. The SNER020L-20 HARRINGTON SNER Electric Chain Hoist will make your lifting tasks a breeze.Capable of lifting Capacity ranging from 2 tons, this electric chain hoist is built to handle even the toughest conditions. Its durable construction ensures long-lasting performance, giving you the peace of mind that it will stand up to the test of time.Installation and operation are made effortless with the compact design of the SNER020L-20 HARRINGTON SNER Electric Chain Hoist. Whether you need to use it in a confined space or transport it to different work sites, this hoist is easy to handle and maneuver.When it comes to power and efficiency, the SNER020L-20 HARRINGTON SNER Electric Chain Hoist does not disappoint. It is equipped with the latest technology to deliver unmatched strength and performance for your lifting projects. You can trust this hoist to handle your heavy loads with ease, saving you time and effort.Upgrade your lifting equipment with the SNER020L-20 HARRINGTON SNER Electric Chain Hoist and experience the difference it can make in your operations. From construction sites to manufacturing facilities, this hoist is the ultimate solution for all your lifting needs. Trust in its power, reliability, and durability to get the job done efficiently and safely.Product Specifications
.Product Videos
Videos Hide Videos Show Videos
Custom Field
Part Number SNER020L-20
Color Yellow
Hoist Lift 20 ft
Product Electric Chain Hoist, 4,000 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley
Includes Chain Container
Lift Speed 7 fpm
Housing Width 13 5/16 in
Manufacturers Warranty Length 1 yr
Housing Depth 8 5/16 in
Housing Length 22 19/32 in
For Minimum Beam Flange Width Not Applicable
For Maximum Beam Flange Width Not Applicable
For Maximum Beam Height Not Applicable
MFR Warranty Length 1 yr
Body Width 13 5/16 in
Body Depth 8 5/16 in
For Minimum Beam Height Not Applicable
Body Length 22 19/32 in
Minimum Radius Curve Not Applicable
Maximum Lifting Length 20 ft
Controller Cord Length 16 ft
Trolley Wheel Diameter Not Applicable
Lifting Hook Opening Width 1 1/2 in
Minimum Retracted Length 22 19/32 in
Load Capacity 4,000 lb
Minimum Between Hooks 22 5/8 in
Motor HP 1.2 hp
Phase 1
Standards ASME B30.16, ASME HST-1, NFPA 70
Voltage 115/230V
Fits Brand Harrington Hoists Inc
Lubrication Oil Bath
Reeving 1
Thermal Protection No
Control Cord 16 ft
Amps @ Low Volts 23.9 A
Number of Speeds 1
Trolley Configuration Hook Mounted
Trolley Speed Not Applicable
Features Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material Die Cast Aluminum
Lifting Hook Material Carbon Steel
Includes Clutch Clutch Included
Overload Protection Included Yes
Brake Type Pull Rotor
Chain Grade Grade 80
Maximum Lift Speed Not Applicable
Included Components Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed 7 fpm
Clutch Type Friction Clutch
Minimum Lift Speed Not Applicable
Pendant IP Rating IP65
Chain Finish Nickel Plated
Controls Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour 360
Duty Classification H4
Maximum Pulling Capacity Not Applicable
Number of Reeves 1
Motor Horsepower 1 1/4 hp
Headroom 22 19/32 in
Includes Brake Brake Included
For Outdoor Use Yes
Hoist IP Rating IP55
Lifting Hook Type Swivel Hook with Safety Latch
Maximum Lifting Capacity 4,000 lb
Current at Minimum Voltage 23.9 A
Trolley Wheel Material Not Applicable
Current at Maximum Voltage 0
Body Finish Enamel
Number of Load Chains 1
Body Material Aluminum
Trolley IP Rating Not Applicable
Programmable Non-Programmable
