SKU:
SNER020L-15-15
Condition:
New
Availability:
In stock
Weight:
117.50 LBS
Shipping:
Free Shipping
Part Number:
SNER020L-15
Color:
Yellow
Hoist Lift:
15 ft
Product:
Electric Chain Hoist, 4,000 lb, 15 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley
Includes:
Chain Container
Lift Speed:
7 fpm
Housing Width:
13 5/16 in
Manufacturers Warranty Length:
1 yr
Housing Depth:
8 5/16 in
Housing Length:
22 19/32 in
For Minimum Beam Flange Width:
Not Applicable
For Maximum Beam Flange Width:
Not Applicable
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
1 yr
Body Width:
13 5/16 in
Body Depth:
8 5/16 in
For Minimum Beam Height:
Not Applicable
Body Length:
22 19/32 in
Minimum Radius Curve:
Not Applicable
Maximum Lifting Length:
15 ft
Controller Cord Length:
11 ft
Trolley Wheel Diameter:
Not Applicable
Lifting Hook Opening Width:
1 1/2 in
Minimum Retracted Length:
22 19/32 in
Load Capacity:
4,000 lb
Minimum Between Hooks:
22 5/8 in
Motor HP:
1.2 hp
Phase:
1
Standards:
ASME B30.16, ASME HST-1, NFPA 70
Voltage:
115/230V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Oil Bath
Reeving:
1
Thermal Protection:
No
Control Cord:
11 ft
Amps @ Low Volts:
23.9 A
Number of Speeds:
1
Trolley Configuration:
Hook Mounted
Trolley Speed:
Not Applicable
Features:
Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
Yes
Brake Type:
Pull Rotor
Chain Grade:
Grade 80
Maximum Lift Speed:
Not Applicable
Included Components:
Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed:
7 fpm
Clutch Type:
Friction Clutch
Minimum Lift Speed:
Not Applicable
Pendant IP Rating:
IP65
Chain Finish:
Nickel Plated
Controls:
Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour:
360
Duty Classification:
H4
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
1 1/4 hp
Headroom:
22 19/32 in
Includes Brake:
Brake Included
For Outdoor Use:
Yes
Hoist IP Rating:
IP55
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
4,000 lb
Current at Minimum Voltage:
23.9 A
Trolley Wheel Material:
Not Applicable
Current at Maximum Voltage:
0
Body Finish:
Enamel
Number of Load Chains:
1
Body Material:
Aluminum
Trolley IP Rating:
Not Applicable
Programmable:
Non-Programmable
