SNER Electric Chain Hoist 10' Lift-Capacity 2 Tons SNER020L Electric Chain Hoist HARRINGTON

Product Overview

The SNER020L-10 HARRINGTON SNER Electric Chain Hoist is more than just an ordinary hoist. It is an industrial-strength machine that is built to handle extreme-duty applications. No matter how heavy your load is, this hoist can handle it with ease.With a load capacity ranging from 2 tons, the SNER020L-10 can lift, lower, or position heavy objects effortlessly. Its single-phase power capability ensures that it can handle heavy-duty tasks in any industrial setting. Whether you need to move heavy machinery or lift heavy materials, this hoist is up to the challenge.One of the standout features of this hoist is its 10-foot lift capacity. This means that it can reach heights that many other hoists can't. It offers the flexibility and reach needed to get the job done efficiently and effectively. No more struggling with height restrictions or limited lifting capacity-the SNER020L-10 can handle even the toughest tasks.Investing in the reliability and performance of the SNER020L-10 HARRINGTON SNER Electric Chain Hoist is a smart choice. It is built to last and can withstand harsh conditions and heavy use. Trustworthy and dependable, this hoist is designed to provide years of trouble-free service.Whether you work in a construction site, warehouse, or any other industrial setting, the SNER020L-10 HARRINGTON SNER Electric Chain Hoist is a must-have tool. It will save you time and effort, making your work easier and more efficient. Don't settle for anything less than the best-choose the SNER020L-10 HARRINGTON SNER Electric Chain Hoist and experience the difference.

Product Specifications

.

Part Number:

SNER020L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 4,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

7 fpm

Housing Width:

13 5/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

8 5/16 in

Housing Length:

22 19/32 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 5/16 in

Body Depth:

8 5/16 in

For Minimum Beam Height:

Not Applicable

Body Length:

22 19/32 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 1/2 in

Minimum Retracted Length:

22 19/32 in

Load Capacity:

4,000 lb

Minimum Between Hooks:

22 5/8 in

Motor HP:

1.2 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Item:

Electric Chain Hoist

Reeving:

1

Thermal Protection:

No

Control Cord:

6 ft

Amps @ Low Volts:

23.9 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

7 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

22 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

4,000 lb

Current at Minimum Voltage:

23.9 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

0

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
