SNER Electric Chain Hoist 20' Lift-Capacity 1 Tons SNER010L Electric Chain Hoist HARRINGTON

Product Overview

The SNER010L-20 HARRINGTON SNER Electric Chain Hoist is engineered for exceptional lifting performance, designed to meet the rigorous demands of both industrial settings and heavy-duty projects. With a maximum lift capacity of 1 ton and a 20-foot lift height, this hoist provides unparalleled power and reliability for tackling the toughest lifting tasks. Its quality construction and robust features make it an invaluable asset for any workplace.

Built to withstand harsh conditions, the SNER010L-20 electric hoist is a testament to HARRINGTON's commitment to excellence. This device operates on single-phase power, making it compatible with standard electrical systems. As a result, users can effortlessly incorporate it into their existing setups without the need for extensive modifications. The ease of use eliminates the strain of manual lifting, allowing operators to focus on efficiency and productivity.

• Heavy-duty 1-ton lift capacity designed for industrial applications.
• 20-foot lifting height to accommodate large loads in various environments.
• Durable construction that ensures longevity and withstands challenging conditions.
• Single-phase power compatibility for easy integration into existing setups.
• User-friendly design that enhances operational safety and efficiency.
• Low maintenance requirements to minimize downtime during operations.

Trust in the legendary reputation of HARRINGTON when it comes to your lifting equipment. The SNER010L-20 Electric Chain Hoist guarantees safe and efficient operation, whether you're moving heavy machinery, construction materials, or other large items. Its remarkable performance ensures that you will increase productivity while minimizing downtime.

Choosing the SNER010L-20 means investing in a lifting solution that promises consistent reliability and strength. Experience the cutting-edge design and robust functionality that this electric hoist offers. Don't compromise on quality; elevate your lifting operations with the SNER010L-20 HARRINGTON SNER Electric Chain Hoist. Discover the difference it can make in your daily tasks and achieve more efficient results today.

Product Specifications

.

Part Number:

SNER010L-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 2,000 lb, 20 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

7 fpm

Housing Width:

10 13/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

7 1/2 in

Housing Length:

16 3/32 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

10 13/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

16 3/32 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

16 3/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

16 in

Motor HP:

0.6 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

No

Brake:

Pull Rotor Motor

Control Cord:

16 ft

Amps @ Low Volts:

16.9 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

7 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

16.9 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

8.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
