SNER Electric Chain Hoist 10' Lift-Capacity 1 Tons SNER010L Electric Chain Hoist HARRINGTON

Product Overview

The SNER010L-10 HARRINGTON SNER Electric Chain Hoist is the ultimate solution for upgrading your lifting operations. With its superior performance and unmatched reliability, this hoist is designed to handle even the most demanding tasks.Operating on a single phase power source, the SNER010L-10 Electric Chain Hoist provides exceptional power and efficiency. Its robust construction ensures long-lasting durability, allowing you to rely on its performance day after day.With a lift capacity ranging from 1 tons, this hoist offers unparalleled versatility. Whether you need to lift heavy machinery or delicate materials, the SNER010L-10 is up to the task. It can tackle a wide range of loads and get the job done with ease.This electric chain hoist is designed with space limitations in mind. Its compact design and 10' lift height make it perfect for industrial environments where space is at a premium. You can trust the SNER010L-10 to maximize productivity and streamline your lifting processes.Harrington is a brand known for its commitment to quality and innovation. When you choose the SNER010L-10, you can be confident that you're investing in a top-of-the-line product.Upgrade your lifting operations today with the SNER010L-10 HARRINGTON SNER Electric Chain Hoist. Experience the difference in performance and efficiency. Order now and take your lifting capabilities to the next level.

Product Specifications

.

Part Number:

SNER010L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 2,000 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley

Includes:

Chain Container

Lift Speed:

7 fpm

Housing Width:

10 13/16 in

Manufacturers Warranty Length:

1 yr

Housing Depth:

7 1/2 in

Housing Length:

16 3/32 in

For Minimum Beam Flange Width:

Not Applicable

For Maximum Beam Flange Width:

Not Applicable

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

10 13/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

Not Applicable

Body Length:

16 3/32 in

Minimum Radius Curve:

Not Applicable

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

Not Applicable

Lifting Hook Opening Width:

1 3/16 in

Minimum Retracted Length:

16 3/32 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

16 in

Motor HP:

0.6 hp

Phase:

1

Standards:

ASME B30.16, ASME HST-1, NFPA 70

Voltage:

115/230V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

No

Classification:

H4

Control Cord:

6 ft

Amps @ Low Volts:

16.9 A

Number of Speeds:

1

Trolley Configuration:

Hook Mounted

Trolley Speed:

Not Applicable

Features:

Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

7 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Hook Mounted-No Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

16.9 A

Trolley Wheel Material:

Not Applicable

Current at Maximum Voltage:

8.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
