SEQP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1/2 Tons EQP005SD Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The SEQP005SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley is the ultimate solution for all your lifting and transporting needs. With its impressive 15' lift capacity, this electric hoist can effortlessly handle heavy loads ranging from 1/2 Tons.Equipped with a dual-speed VFD control, this chain hoist allows for precise and accurate operation, maximizing productivity and efficiency. Its push trolley design ensures easy maneuverability, making it perfect for use in warehouses, workshops, and construction sites.Crafted to the highest standards of quality and durability, this electric chain hoist can withstand even the toughest conditions, providing unmatched performance and longevity. The SEQP005SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley is a reliable and dependable tool that you can trust for all your lifting needs.By investing in this electric chain hoist, you not only enhance your productivity but also improve your overall workflow. It eliminates the need for manual lifting, reducing the risk of injuries and strain on your employees. With its powerful motor and robust construction, this chain hoist effortlessly handles even the most demanding lifting tasks.Aside from its exceptional functionality, the SEQP005SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley offers convenience and ease of use. Its user-friendly design, intuitive controls, and simple set-up process allow you to start using the hoist immediately, saving you valuable time and effort.In summary, the SEQP005SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley is a top-of-the-line hoisting solution that delivers unbeatable performance and reliability. Whether you need to lift heavy loads in a warehouse or transport materials on a construction site, this hoist is the perfect choice. Invest in the SEQP005SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley and experience the difference it can make in your operations.

Product Specifications

.

Part Number:

SEQP005SD-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 1,000 lb, 15 ft, Push Trolley, Yellow=Hoist Mount=Push Trolley

Includes:

Chain Container

Lift Speed:

25/4.2 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 29/32 in

For Minimum Beam Flange Width:

2 1/2 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 29/32 in

Minimum Radius Curve:

43 1/4 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

3 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 29/32 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

16 7/8 in

Motor HP:

1 hp

Phase:

1

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

115V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Finish:

Epoxy Painted

Amps @ Low Volts:

14.8 A

Number of Speeds:

2

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

25 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

4.2 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Push Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 hp

Headroom:

16 13/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

14.9 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

0.375

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
