SEQP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 1/4 Tons EQP003SD Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Transport heavy loads effortlessly with the SEQP003SD-10 HARRINGTON SEQP Electric Chain Hoist with Push Trolley. This high-quality hoist combines the power of a single-phase dual-speed electric chain hoist with the convenience of a PT push trolley, making it an ideal solution for lifting and moving objects.With a 10' lift capacity and a range of 1/4 Tons, this hoist is suitable for a variety of applications. Whether you need to lift heavy machinery in a manufacturing facility or transport goods in a warehouse, this hoist will get the job done efficiently and safely.The VFD control on this hoist allows for easy speed adjustment, ensuring smooth and precise operation. You can easily control the lifting speed to match the requirements of the load, enhancing productivity and reducing the risk of accidents.The SEQP003SD-10 HARRINGTON SEQP Electric Chain Hoist with Push Trolley is built to last. Its durable construction ensures longevity and reliable performance, saving you time and money on maintenance and repairs.This hoist is also designed with user convenience in mind. The PT push trolley allows for easy positioning and maneuverability, making it simple to transport heavy loads from one place to another.Whether you are in the construction industry, manufacturing, or any other field that requires heavy lifting, the SEQP003SD-10 HARRINGTON SEQP Electric Chain Hoist with Push Trolley is an essential tool. Upgrade your lifting capabilities with this reliable and efficient hoist today!

Product Specifications

.

Part Number:

SEQP003SD-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb., 10 ft, Push Trolley, Yellow=Hoist Mount=Push Trolley

Includes:

Chain Container

Lift Speed:

33/5.5 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 19/64 in

For Minimum Beam Flange Width:

2 1/2 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 5/16 in

Minimum Radius Curve:

43 1/4 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

3 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

500 lb.

Minimum Between Hooks:

16 5/16 in

Motor HP:

0.67 hp

Phase:

1

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

115V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

12.3 A

Number of Speeds:

2

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

33 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

5.5 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

12.7 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.2 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
