SEQP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 1/8 Tons EQP001SD Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The SEQP001SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley is engineered to revolutionize your load transportation needs, streamlining operations and enhancing productivity across various sectors. Embrace a new era of lifting with this robust hoist that eliminates the challenges of manual handling, allowing you to engage in hassle-free and efficient lifting operations.

With advanced Variable Frequency Drive (VFD) control, this electric chain hoist operates at dual speeds, delivering unparalleled precision and control during the lifting process. Forget the days of labor-intensive hoisting; the SEQP001SD-15 ensures smooth, consistent, and reliable load movement. Whether in a warehouse, construction site, or an industrial environment, this hoist's impressive lift capacity and versatility make it an indispensable tool.

• Lift capacity of 15 feet, accommodating weights of up to 1/8 tons
• Dual-speed operation features for greater control and efficiency
• Seamless integration with the PT push trolley for smooth movement along overhead beams
• Ideal for various applications including warehouses, construction sites, and industrial facilities
• Built with quality components to withstand tough job site conditions
• Enhanced productivity, safety, and operational efficiency

This electric chain hoist is not just about lifting; it’s about lifting smart. The push trolley component further enhances usability, enabling smooth and effortless transitions across your workspace. The intelligent design means that HARRINGTON has prioritized convenience, allowing operators to focus on their tasks without getting bogged down by cumbersome equipment.

Investing in the SEQP001SD-15 equates to embracing superior technology that ensures your workload is handled with the utmost care and efficiency. HARRINGTON is recognized for its high-quality machinery, creating equipment that meets rigorous standards and delivers reliable performance, even in the most demanding environments. When you choose HARRINGTON, you're not just investing in a product, you're securing your operational success.

Elevate your lifting capabilities with the SEQP001SD-15 HARRINGTON SEQP Electric Chain Hoist with Push Trolley. Your lifting operations deserve the best—don't compromise on quality. Experience the difference that top-tier equipment can make in your daily tasks. Opt for efficiency, reliability, and safety with HARRINGTON, and transform your lifting operations forever.

Product Specifications

.

Part Number:

SEQP001SD-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 250 lb, 15 ft, Push Trolley, Yellow=Hoist Mount=Push Trolley

Includes:

Chain Container

Lift Speed:

56/9.3 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 19/64 in

For Minimum Beam Flange Width:

2 1/2 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 5/16 in

Minimum Radius Curve:

43 1/4 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

3 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

250 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

0.67 hp

Phase:

1

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

115V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

10.8 A

Number of Speeds:

2

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

56 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

9.3 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

250 lb

Current at Minimum Voltage:

0.458333333333333

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.1 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
