SEQG Electric Chain Hoist with Geared Trolley 20' Lift-Capacity 1/2 Ton EQG005SD Electric Chain Hoist with Geared Trolley HARRINGTON
Write a Review
Write a Review
HARRINGTON HOIST
SEQG Electric Chain Hoist with Geared Trolley 20' Lift-Capacity 1/2 Ton EQG005SD Electric Chain Hoist with Geared Trolley HARRINGTON
$4,388.78
$3,675.05
(You save
$713.73
)
SKU:
SEQG005SD-20-20
Condition:
New
Availability:
In stock
Weight:
101.80 LBS
Shipping:
Free Shipping
Part Number:
SEQG005SD-20
Color:
Yellow
Hoist Lift:
20 ft
Product:
Electric Chain Hoist, 1,000 lb, 20 ft, Geared Trolley, Yellow=Hoist Mount=Geared Trolley
Includes:
Chain Container
Lift Speed:
25/4.2 fpm
Housing Width:
14 13/32 in
Manufacturers Warranty Length:
3 yr
Housing Depth:
9 7/64 in
Housing Length:
17 19/64 in
For Minimum Beam Flange Width:
2 1/4 in
For Maximum Beam Flange Width:
5 in
For Maximum Beam Height:
Not Applicable
MFR Warranty Length:
3 yr
Body Width:
14 13/32 in
Body Depth:
9 1/8 in
For Minimum Beam Height:
3 in
Body Length:
17 5/16 in
Minimum Radius Curve:
51 1/4 in
Maximum Lifting Length:
20 ft
Controller Cord Length:
16 ft
Trolley Wheel Diameter:
4 1/4 in
Lifting Hook Opening Width:
1 3/32 in
Minimum Retracted Length:
17 5/16 in
Load Capacity:
1,000 lb
Minimum Between Hooks:
17 5/16 in
Motor HP:
1 hp
Phase:
1
Standards:
ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A
Voltage:
115V
Fits Brand:
Harrington Hoists Inc
Lubrication:
Oil Bath
Reeving:
1
Thermal Protection:
Yes
Control Cord:
16 ft
Amps @ Low Volts:
14.8 A
Number of Speeds:
2
Trolley Configuration:
Geared Trolley
Trolley Speed:
Not Applicable
Features:
No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)
Lifting Hook Material:
Carbon Steel
Includes Clutch:
Clutch Included
Overload Protection Included:
Yes
Brake Type:
Pull Rotor
Chain Grade:
Grade 80
Maximum Lift Speed:
25 fpm
Included Components:
Chain Container, Pendant, Safety Latch Hook
Fixed Lift Speed:
Not Applicable
Clutch Type:
Friction
Minimum Lift Speed:
4.2 fpm
Pendant IP Rating:
IP65
Chain Finish:
Nickel Plated
Controls:
Push Button Pendant=Mount Type=Geared Trolley
Starts and Stops per Hour:
120, 240
Duty Classification:
H4
Maximum Pulling Capacity:
Not Applicable
Number of Reeves:
1
Motor Horsepower:
1 hp
Headroom:
17 5/16 in
Includes Brake:
Brake Included
For Outdoor Use:
Yes
Hoist IP Rating:
IP55
Lifting Hook Type:
Swivel Hook with Safety Latch
Maximum Lifting Capacity:
1,000 lb
Current at Minimum Voltage:
14.9 A
Trolley Wheel Material:
Steel
Current at Maximum Voltage:
0.375
Body Finish:
Epoxy Painted
Number of Load Chains:
1
Body Material:
Aluminum
Trolley IP Rating:
Not Applicable
Programmable:
Programmable by Internal Controls
The SEQG005SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley is a powerhouse tool that will upgrade your lifting capabilities in an instant. With a lifting capacity of 1/2 Ton this electric chain hoist is designed to effortlessly transport heavy loads with ease. One of the standout features of this hoist is its VFD control for dual-speed operation. This allows for precise and efficient lifting, as you can easily adjust the lifting speed to match your specific needs. Whether you need a quicker lift or a slower, more controlled movement, this hoist has got you covered.Durability and reliability are key when it comes to any material handling equipment, and the SEQG005SD-20 HARRINGTON SEQG Electric Chain Hoist does not disappoint. Built with rugged construction, this hoist can withstand even the toughest environments, ensuring that it will be a long-lasting investment for your business.The true value of this product lies in its combination with the geared trolley. This cost-effective solution provides an all-in-one package for your material handling requirements. The geared trolley allows for smooth movement along the support beam, making it easy to transport your heavy loads with minimal effort.When it comes to electric chain hoists, trust Harrington's expertise. With their years of experience in the industry, you can be confident that you are investing in a high-performing and reliable product. Don't let inefficient lifting slow down your workflow-enhance your productivity with the SEQG005SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley.
