SEQG Electric Chain Hoist with Geared Trolley 20' Lift-Capacity 1/4 Ton EQG003SD Electric Chain Hoist with Geared Trolley HARRINGTON

Product Overview

Upgrade your material handling capabilities with the rugged and reliable SEQG003SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley. Designed to effortlessly transport heavy loads, this hoist is a game-changer in industrial applications. Featuring a dual speed VFD control, you can easily adjust the lifting speed to precisely meet your needs. The durability of this hoist is unmatched. Crafted from only the highest-quality materials, it is built to withstand the toughest conditions. No matter how demanding your workload may be, the SEQG003SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley is up to the task. Efficiency is key, and this hoist delivers on that front as well. The geared trolley provides smooth and seamless movement, ensuring that your materials are transported with precision and speed. Say goodbye to inefficient and time-consuming processes, and hello to a seamless and streamlined experience with the SEQG003SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley. With Capacity ranging from 1/4 Ton, this hoist is perfect for a wide range of lifting tasks. Whether you need to move light or heavy loads, the SEQG003SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley has you covered. Not only does this hoist possess unmatched power and versatility, but it also boasts a lift height of 20 feet. This impressive height gives you the flexibility you need to tackle a wide range of lifting tasks. From warehouses to construction sites, the SEQG003SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley is the perfect companion for all your material handling needs. Experience superior performance, reliability, and efficiency with the SEQG003SD-20 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley. Upgrade your operations today and witness the transformative power of this exceptional product.

Product Specifications

.

Part Number:

SEQG003SD-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 500 lb., 20 ft, Geared Trolley, Yellow=Hoist Mount=Geared Trolley

Includes:

Chain Container

Lift Speed:

33/5.5 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 45/64 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 23/32 in

Minimum Radius Curve:

51 1/4 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

4 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 11/16 in

Load Capacity:

500 lb.

Minimum Between Hooks:

16 7/16 in

Motor HP:

0.67 hp

Phase:

1

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

115V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

16 ft

Amps @ Low Volts:

12.3 A

Number of Speeds:

2

Trolley Configuration:

Geared Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

33 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

5.5 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Programmable by Internal Controls=Mount Type=Geared Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 13/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

12.7 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.2 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
