SEQG Electric Chain Hoist with Geared Trolley 10' Lift-Capacity 1/4 Ton EQG003SD Electric Chain Hoist with Geared Trolley HARRINGTON

Product Overview

The SEQG003SD-10 HARRINGTON SEQG Electric Chain Hoist with Geared Trolley offers unparalleled lifting capabilities for your industrial applications. With a robust lift capacity of 1/4 ton and a height of 10 feet, this electric hoist is engineered to tackle even the most challenging lifting tasks with ease and precision. Designed for efficiency, the hoist features dual-speed VFD control, allowing operators to switch between slow, meticulous lifts and faster operations, catering to various lifting scenarios seamlessly.

Rugged and durable, the SEQG003SD-10 is built to withstand the rigors of demanding industrial environments. Its high-quality construction ensures that it can handle heavy loads while maintaining reliable performance, making it a long-lasting investment for your operation. The included geared trolley enhances its functionality, providing smooth and precise navigation along beams. This not only increases operational efficiency but also minimizes the risk of accidents, ensuring a safer working environment.

Ideal for use in manufacturing, construction, and beyond, the SEQG Electric Chain Hoist is a transformative tool for enhancing productivity. Its powerful performance streamlines lifting processes, allowing workers to complete tasks more quickly and efficiently. Whether you are lifting heavy machinery, materials, or equipment, this hoist combines strength with ease of use, empowering operators to accomplish their goals with confidence.

Embrace the future of lifting with the SEQG003SD-10 HARRINGTON Electric Chain Hoist. Its reliable performance and intelligent design will elevate your operational capabilities, allowing your team to work smarter and achieve greater results. Experience the benefits of advanced lifting technology and take your productivity to unprecedented levels with this exceptional electric chain hoist and geared trolley combination.

Product Specifications

.

Part Number:

SEQG003SD-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 500 lb., 10 ft, Geared Trolley, Yellow=Hoist Mount=Geared Trolley

Includes:

Chain Container

Lift Speed:

33/5.5 fpm

Housing Width:

14 13/32 in

Manufacturers Warranty Length:

3 yr

Housing Depth:

9 7/64 in

Housing Length:

16 45/64 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

3 yr

Body Width:

14 13/32 in

Body Depth:

9 1/8 in

For Minimum Beam Height:

3 in

Body Length:

16 23/32 in

Minimum Radius Curve:

51 1/4 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

4 1/4 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 11/16 in

Load Capacity:

500 lb.

Minimum Between Hooks:

16 7/16 in

Motor HP:

0.67 hp

Phase:

1

Standards:

ASME HST-4, C22.2 No.33/14-13/66, CSA, UL 508A

Voltage:

115V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Clutch:

Friction

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

12.3 A

Number of Speeds:

2

Trolley Configuration:

Geared Trolley

Trolley Speed:

Not Applicable

Features:

No-Load High Speed, Self-Adjusting Maintenance-Free Brake, Unique Chain Guide, Variable Frequency Drive (VFD)

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

Pull Rotor

Chain Grade:

Grade 80

Maximum Lift Speed:

33 fpm

Included Components:

Chain Container, Pendant, Safety Latch Hook

Fixed Lift Speed:

Not Applicable

Clutch Type:

Friction

Minimum Lift Speed:

5.5 fpm

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Geared Trolley

Starts and Stops per Hour:

120, 240

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

5/8 hp

Headroom:

16 13/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

500 lb

Current at Minimum Voltage:

12.7 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.2 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Programmable by Internal Controls
