Tractel Mobile GripWinch® MG503-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase

Write a Review
$32,536.99
SKU: MG503-50
Weight: 160.00 LBS
Width: 29.10 (in)
Height: 22.00 (in)
Depth: 18.90 (in)
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Tractel Mobile GripWinch® MG503-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase

Tractel Mobile GripWinch® MG503-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase

$32,536.99

Tractel Mobile GripWinch® MG503-50 Wire Rope Hoist — 500 kg (1,100 lb) Capacity, Two-Speed, Three-Phase, 33/70 fpm (10/21 m/min)

The Mobile GripWinch MG503-50 delivers versatile lifting and pulling performance in a compact, portable design. With dual-speed operation, it’s ideal for construction, maintenance, and industrial applications where both precision and speed are required.

Product Description

The MG503-50 is powered by a three-phase motor rated at 5.5/10 amps, lifting up to 500 kg (1,100 lb) at two selectable speeds: 33 ft/min (10 m/min) for controlled lifts and 70 ft/min (21 m/min) for faster operation. It supports up to 160 ft (50 m) of 5/16 in. (8.4 mm) wire rope, giving flexibility for longer lifts or varying jobsite needs.

Hoist uses a traction-based drive to ensure smooth, consistent lifting and pulling at both speeds. Compact and rugged, the MG503-50 is easy to transport and set up. Operators benefit from straightforward controls, automatic braking, and load control, allowing safe and efficient operation.

Built for reliability, this hoist requires minimal maintenance, keeping downtime low and productivity high.

Key Specifications

  • Rated Capacity: 500 kg (1,100 lb)
  • Motor Type: Two-speed, three-phase electric motor, 5.5/10 A
  • Lifting Speeds: 33 / 70 ft/min (10 / 21 m/min)
  • Maximum Wire Rope Length: 160 ft (50 m)
  • Wire Rope Diameter: 5/16 in. (8.4 mm)
  • Drive System: Traction-based for smooth lifting and pulling
  • Controls: Simple up/down operation
  • Safety Features: Automatic brake, load control
  • Applications: Mobile lifting, pulling, scaffold or material handling
  • Maintenance: Low-maintenance design for long-term reliability

Why Choose the Mobile GripWinch MG503-50?

  • Dual-speed operation for precise or fast lifts
  • Smooth, consistent performance even with longer rope lengths
  • Portable and durable for versatile jobsite use
  • Built-in safety features to protect operators and loads
  • Low-maintenance design ensures long-term dependability
Tractel offers various warranties depending on the product, with a general warranty of 24 months on products manufactured by the seller for defects in materials and workmanship. Some specific products, like the tralift™ TT Electric chain hoist, may have a longer 3-year warranty. The warranty typically excludes issues from improper storage, assembly, maintenance, use, or unauthorized modifications and does not cover normal wear or paints.  Key Aspects of a Tractel Warranty:  Duration: The standard warranty period is 24 months (two years) from the date on the order invoice. Coverage: The warranty covers defects in materials and workmanship. Exclusions: The warranty generally does not cover: Improper storage or assembly. Insufficient maintenance or failure to follow operating instructions. Abnormal working conditions. Normal wear and tear. Willful or negligent damage. Modifications or repairs by personnel not certified by Tractel. Paints and coatings. How to Get More Information:  Check Product-Specific Details:  Always refer to the product's documentation or visit the Tractel US website for the exact warranty terms for your specific item. Contact Tractel:  For clarification on a specific warranty or to inquire about a potential claim, contact Tractel directly.
