Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
video
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly

  • Guaranteed Fitment

    Always the correct part

  • In-House Experts

    We know our products

  • Added Value

    FREE in house engineering and design assistance

  • Wordwide Delivery

    Free shipping on all Harrington orders over 500LBS

Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly

Write a Review
$7,399.99
SKU: 032199024200K
Weight: 117.33 LBS
Width: 6.00 (in)
Height: 12.75 (in)
Depth: 27.50 (in)
Shipping: Calculated at Checkout
Adding to cart… The item has been added
Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly

Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly

$7,399.99
Description

Tractel Griphoist / Tirfor TU32 Manual Wire Rope Hoist – 3.2 Ton Capacity, 200 ft (60 m) Assembly

Product Description

The Tractel Griphoist / Tirfor TU32 is equipped with a 200 ft (60 m) wire rope assembly, that delivers exceptional performance for heavy-duty lifting, pulling, and positioning. With a 7,000 lb (3.2 ton) capacity, this model is suited for construction projects, utility work, steel erection, and demanding rigging operations where safety and strength are paramount.

The included 200-foot wire rope assembly makes this hoist ready to use upon arrival. Thanks to its pass-through wire rope system, the TU32 can also operate over unlimited distances with longer ropes, offering unmatched versatility.

Engineered with a dual jaw load-holding system for secure operation and equipped with shear pins for overload protection, the TU32 with 200 ft assembly delivers reliable manual power in environments where mechanical handling or powered hoists are not an option.

Key Specifications

  • Model / SKU: TU32 – 200 ft Assembly
  • Type: Griphoist / Tirfor TU32
  • Nominal Capacity: 7,000 lbs (3,200 kg)
  • Wire Rope Diameter: 5/8 in (16.3 mm)
  • Wire Rope Length: 200ft (60 m) assembly included
  • Unit Weight (hoist body): 64 lbs (23 kg)
  • Wire Rope Weight (30 ft): 8 lbs (3.5 kg)
  • Effort on Lever (Forward): 119 lbs (54 kg)
  • Effort on Lever (Reverse): 55 lbs (25 kg)
  • Rope Travel per Forward Stroke: 2 13/64 in (30 mm)
  • Rope Travel per Reverse Stroke: 2 3/4 in (48 mm)
  • Minimum Wire Rope Breaking Strength: 40,000 lbs (18,144 kg)
  • Safety Factor: 4:1 (material handling applications)
  • Operation Modes: Horizontal, vertical, or angled pulling and lifting
  • Safety Features: Dual jaw gripping system; overload shear pins
  • Compliance: Meets ASME B30.21 standards
Warranty Information
Tractel offers various warranties depending on the product, with a general warranty of 24 months on products manufactured by the seller for defects in materials and workmanship. Some specific products, like the tralift™ TT Electric chain hoist, may have a longer 3-year warranty. The warranty typically excludes issues from improper storage, assembly, maintenance, use, or unauthorized modifications and does not cover normal wear or paints.  Key Aspects of a Tractel Warranty:  Duration: The standard warranty period is 24 months (two years) from the date on the order invoice. Coverage: The warranty covers defects in materials and workmanship. Exclusions: The warranty generally does not cover: Improper storage or assembly. Insufficient maintenance or failure to follow operating instructions. Abnormal working conditions. Normal wear and tear. Willful or negligent damage. Modifications or repairs by personnel not certified by Tractel. Paints and coatings. How to Get More Information:  Check Product-Specific Details:  Always refer to the product's documentation or visit the Tractel US website for the exact warranty terms for your specific item. Contact Tractel:  For clarification on a specific warranty or to inquire about a potential claim, contact Tractel directly.
