The Conductix_Wampfler XA_EHL_1TS Air Hoist is an efficient, single_chain pneumatic lifting unit engineered for lifting up to 1_ton (1,000_kg, 2,200_lb) with precision and reliability. Part of the compact EHL_TS Series, it delivers high-performance operation in a smaller and lighter form factor than double-chain variants . This hoist includes a 3-meter (9.8_ft) pull_chain control as standard, with an optional pendant-style control available. Lift chain length can be tailored between 1_m and 20_m, enabling flexible integration into diverse application settings . Powered by lubricated compressed air via an Rp_1/2 inlet, the XA_EHL_1TS employs a rotary_vane motor and automatic friction brake for smooth lifting and reliable load holding without frequent maintenance adjustments Weighing significantly less than comparable double_chain hoists (approximately 53_lb / 24_kg for the double-chain 1_TW model), the XA_EHL_1TS reduces headroom requirements and simplifies suspension mounting—ideal for cranes, trolleys, jib arms, and other installations in heavy-duty manufacturing, maintenance, and assembly environments . Key Features: Load Capacity: 1,000_kg (2,200_lb) Chain Length: 3_m (standard); adjustable from 1_m to 20_m Control Options: Pull-chain standard; optional pendant control Air Inlet: Rp_1/2 (lubricated compressed air) Brake: Automatic, maintenance_free friction brake Hoist Mechanism: Single-chain, rotary_vane motor Design: Compact and lightweight for limited headroom installation Applications: Overhead cranes, monorails, pendants, air/manual trolleys, etc.
