The XA_110CGX Expansion Gap Kit is engineered to manage deliberate conductor separation in Saf_T_Bar C_Series systems. Ideal for installations that require expansion control or custom field-cut adjustments, this kit accommodates gaps of up to 2_ based on rail type and operating conditions. It includes a guide bracket and necessary jumper cable(s), allowing continuous electrical flow and secure collector tracking across the separation. Tandem collector use is recommended to ensure reliable power pickup through the gap.
Key Features
Supports 110_A conductor systems — fits standard C_Series configurations.
Adjustable gap management — designed for up to 2_ separation based on environmental and thermal needs.
Jumper and power feed components included — ensures uninterrupted power across gaps.
Mounting bracket included — secures the expansion section and collector alignment.
Easy field installation — allows gap creation without replacing full-length rails.
Technical Specifications
Specification Details
Part Number XA_110CGX
Series Saf_T_Bar C_Series
Applicable Rating 110_A
Gap Capacity Up to 2_ (50_mm), adjustable
Included Components Guide bracket, jumper cable(s), power feed(s)
Intended Use Managing thermal/structural expansion; field gap installations
Collector Recommendation Tandem collectors to ensure continuity
