Saf-T-Bar, C-Series, BAR XFR GAP GDE ASSY C BAR TRANSFER GAP GUIDE ASSEMBLY Conductix XA-CT100

The XA_CT100 Transfer Gap Guide Assembly helps ensure uninterrupted collector shoe tracking over transfer or expansion gaps in Saf_T_Bar C_Series conductor systems. It compensates for misalignment tolerances of up to ~__ laterally and directionally, guiding the collector smoothly between sections. Ideal for bridging bar transitions or longer runs with slight rail deviation, this assembly reduces power interruptions when paired with standard or tandem collector configurations. It includes mounting hardware and electrical jumpers to maintain conductivity across the gap. Key Features Misalignment compensation – Guides collectors smoothly over lateral misalignments of ~3–13_mm and small vertical shifts. Continuity jumper included – Electrical jumper and extra powerfeed(s) are supplied to maintain current across the gap. crane-controls.com Simple mounting – The unit snaps onto existing C_Series bars with a guide bracket; designed to replace one conductor bar length. Supports tandem collectors – Recommended for systems sensitive to momentary power interruptions. Industrial-grade construction – Built for durability in dynamic overhead power applications. Technical Specifications Spec Metric Details Part Number XA_CT100 Series Saf_T_Bar C_Series Function Guides collectors over misaligned or gapped conductor bar sections Alignment Compensation Up to ~__ (3_–_13_mm) laterally and ~__ vertically Included Components Guide bracket, jumper cable, and extra powerfeed(s) Replacement Length Occupies one standard conductor bar section (typically 10_ft) Collector Usage Supports systems using standard or tandem collectors
