PL36 – A mechanical post lift table with a 2,000 lb capacity, a 24″ × 36″ platform, and hand-crank operation—ideal for precise, power-free lifting and positioning in tight workspaces or mobile setups.

Product Description

Need a reliable lifting solution when power isn’t an option? The PL36 Mechanical Post Lift Table offers high-capacity strength, precise control, and simplicity in operation. Built for workshop floors, maintenance bays, production areas, and anywhere you require dependable mechanical lifting, this post lift table allows you to raise and position heavy loads smoothly—without electricity.

With a 2,000 lb (907 kg) rated capacity, the PL36 is well suited for heavy components, molds, tooling, and material loads. Its 24″ × 36″ platform gives you a stable surface while keeping the overall footprint compact enough to pass through narrow aisles or fit beside workstations.

The lifting system is purely mechanical: a hand crank drive turns four acme screw posts, delivering precise height adjustment and positive load holding (no drift). The crank mechanism offers dual-speed operation—one speed for rapid elevation, the other for fine adjustment—so you can move loads quickly or make subtle alignment changes. Because it’s manual, the unit works anywhere, including power-restricted areas or remote locations.

Stability and mobility are engineered into the PL36. It rides on two rigid and two swivel phenolic casters, allowing easy rolling to the desired location. A foot-operated floor lock secures the unit during lifting or positioning operations, ensuring a safe and stable working platform.

Constructed from heavy-duty welded steel, the PL36 includes guide posts to maintain alignment through the travel range and a robust frame designed to resist twisting or misalignment under load. Its mechanical simplicity means fewer components to maintain—no motors, no hydraulics, no batteries.

Whether you need to lift, position, or stage heavy materials in a power-free setting, the PL36 Mechanical Post Lift Table offers dependable performance, precision, and rugged durability in tight or mobile environments.

Specifications

• Model / SKU: PL36

• Type: Mechanical post lift table

• Load Capacity: 2,000 lb (907 kg)

• Platform Size: 24″ (W) × 36″ (L)

• Lift Mechanism: Manual hand-crank drive

• Lifting Posts: Four self-locking acme screw posts (no load drift)

• Crank Operation: Dual-speed crank (fast and fine modes)

• Mobility: Two rigid and two swivel phenolic casters

• Locking Mechanism: Foot-operated floor lock for secure positioning

• Frame: Heavy-duty welded steel with guide posts for stability

• Approximate Travel Range: ~ 18″ vertical travel (typical for mechanical post tables)

• Ideal Uses: Tool & die handling, assembly support, staging heavy parts, maintenance operations
