NER Electric Chain Hoist Lift-Capacity 1/4 Tons NER003S Electric Chain Hoist HARRINGTON

Write a Review
$2,921.43 - $3,177.58
SKU: NER003S-10
Condition: New
Weight: 86.00 LBS
Width: 18.00 (in)
Height: 19.00 (in)
Depth: 25.00 (in)
Shipping: Free Shipping
Part Number: NER003S-10
Color: Yellow
Hoist Lift: 10 ft
Product: Electric Chain Hoist, 500 lb, 10 ft, Hook Mounted-No Trolley, Yellow=Hoist Mount=Hook Mounted-No Trolley
Includes: Chain Container, Quick Disconnect Plugs On Pendant and Power Cords, 10 yr Brake Warranty
Lift Speed: 36 fpm
Housing Width: 12 19/32 in
Manufacturers Warranty Length: 10 yr Brake Warranty, 3 yr
Housing Depth: 6 5/8 in
Housing Length: 18 13/16 in
For Minimum Beam Flange Width: Not Applicable
For Maximum Beam Flange Width: Not Applicable
For Maximum Beam Height: Not Applicable
MFR Warranty Length: 1 yr
Body Width: 12 19/32 in
Body Depth: 6 5/8 in
For Minimum Beam Height: Not Applicable
Body Length: 18 13/16 in
Minimum Radius Curve: Not Applicable
Maximum Lifting Length: 10 ft
Controller Cord Length: 8 3/16 ft
Trolley Wheel Diameter: Not Applicable
Lifting Hook Opening Width: 1 3/32 in
Minimum Retracted Length: 13 13/16 in
Load Capacity: 500 lb
Minimum Between Hooks: 13 13/16 in
Motor HP: 0.75 hp
Phase: 3
Standards: ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70, UL 1340
Voltage: 208/230/460V
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Reeving: 1
Thermal Protection: Yes
Control Cord: 6 ft
Amps @ Low Volts: 3.4 A
Number of Speeds: 1
Trolley Configuration: Hook Mounted-No Trolley
Trolley Speed: Not Applicable
Features: Count Hour Meter, Dual Speed VFD, Easy Access Suspension, Extreme Duty Motor, Secondary Brake, Smart Brake Technology, State-Of-The-Art Chain Technology, Unique Smart Limit Option
Lifting Hook Material: Carbon Steel
Includes Clutch: Clutch Included
Overload Protection Included: Yes
Brake Type: DC Current
Chain Grade: Grade 80
Maximum Lift Speed: Not Applicable
Included Components: Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook
Fixed Lift Speed: 36 fpm
Clutch Type: Friction Clutch
Minimum Lift Speed: Not Applicable
Pendant IP Rating: IP65
Chain Finish: Nickel Plated
Controls: Push Button Pendant=Mount Type=Hook Mounted-No Trolley
Starts and Stops per Hour: 360
Duty Classification: H4
Maximum Pulling Capacity: Not Applicable
Number of Reeves: 1
Motor Horsepower: 3/4 hp
Headroom: 13 13/16 in
Includes Brake: Brake Included
For Outdoor Use: Yes
Hoist IP Rating: IP55
Lifting Hook Type: Swivel Hook with Safety Latch
Maximum Lifting Capacity: 500 lb
Current at Minimum Voltage: 3.4 A
Trolley Wheel Material: Not Applicable
Current at Maximum Voltage: 1.7 A
Body Finish: Painted
Number of Load Chains: 1
Body Material: Aluminum
Trolley IP Rating: Not Applicable
Programmable: Non-Programmable
Adding to cart… The item has been added
NER Electric Chain Hoist Lift-Capacity 1/4 Tons NER003S Electric Chain Hoist HARRINGTON

NER Electric Chain Hoist Lift-Capacity 1/4 Tons NER003S Electric Chain Hoist HARRINGTON

$2,921.43 - $3,177.58

NER Electric Chain Hoist Lift-Capacity 1/4 Tons NER003S Electric Chain Hoist HARRINGTON

$2,921.43 - $3,177.58

The NER003S HARRINGTON NER Electric Chain Hoist is a powerhouse solution tailored for those who demand efficiency and reliability in their lifting operations. With an impressive lifting capacity of 1/4 tons and a height of 10 feet, this electric chain hoist is engineered to meet the rigorous demands of various industries, including construction, manufacturing, and warehouses.

Designed to handle heavy lifting with utmost ease, the NER003S boasts advanced technology that ensures smooth, seamless operations. This electric hoist is not just about lifting; it's about enhancing operational efficiency and reducing the risk of strain or injury for those on the job. Built with top-of-the-line materials, its construction promises durability even in the toughest working environments, ensuring a long lifespan and minimal maintenance needs.

Safety is paramount in heavy lifting, and the NER003S excels in this area with its array of protective features. Operators and loads are safeguarded, allowing for worry-free operations. This hoist is built to withstand not just the weight of the loads it lifts, but also the rigors of daily use, making it an indispensable tool for any lifting task.

Furthermore, its versatility allows it to adapt to various applications, making it an excellent investment for anyone looking to enhance their lifting capabilities. Experience the difference that powerful, reliable lifting can make in your work with the NER003S HARRINGTON NER Electric Chain Hoist. This hoist is more than just a tool; its a commitment to productivity and safety, elevating your operations to new heights with every lift.

Buyer must notify HHI in writing within sixty (60) days of discovery of any alleged defect, if within the applicable warranty period. All products sold by HHI are warranted to be free from defects in material and workmanship from date of shipment by HHI for the following periods: 1 year – Electric and Air Powered Hoists (excluding (N)ER2 Hoists and EQ/SEQ Hoists), Powered Trolleys, Powered Tiger Track Jibs and Gantries, Crane Components, Below the Hook Devices, Spare / Replacement Parts 2 years – Manual Hoists & Trolleys, Beam Clamps 3 years – (N)ER2 Hoists, EQ/SEQ Hoists, (T)EM/(T)SEM hoists, and RY Hoists 5 years – Manual Tiger Track Jibs and Gantries, Hoist Motor Brakes for EQ/SEQ, (T)EM/(T)SEM, and RY 10 years – (N)ER2 Brake, TNER Hoist Motor Brake The product must be used in accordance with manufacturer’s recommendations and must not have been subject to abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. Should any defect in material or workmanship occur during the above time period in any product, as determined by HHI’s inspection of the product, HHI agrees, at its discretion, either to replace (not including installation) or repair the part or product free of charge. For customers in the U.S., delivery shall be made F.O.B. HHI’s place of business. For international customers, delivery shall be made FCA HHI place of business, United States of America (Incoterms 2010). No warranty claim will be honored without a valid proof of purchase. Customer must obtain a Return Goods Authorization as directed by HHI or its published repair center prior to shipping product for warranty evaluation. An explanation of the complaint must accompany the product. Product must be returned freight prepaid. Upon repair, the product will be covered for the remainder of the original warranty period. Replacement parts installed after the original warranty period will only be eligible for replacement (not including installation) for a period of one year from the installation date. If it is determined there is no defect, or that the defect resulted from causes not within the scope of HHI’s warranty, the customer will be responsible for the costs of returning the product. HHI DISCLAIMS ANY AND ALL OTHER WARRANTIES OF ANY KIND, EXPRESSED OR IMPLIED, AS TO THE PRODUCT’S MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE. HHI WILL NOT BE LIABLE FOR DEATH, INJURIES TO PERSONS OR PROPERTY OR FOR INCIDENTAL, CONTINGENT, SPECIAL OR CONSEQUENTIAL DAMAGES, LOSS OR EXPENSE ARISING IN CONNECTION WITH THE USE OR MISUSE OF THE PRODUCTS, REGARDLESS OF WHETHER THE DAMAGE, LOSS OR EXPENSE RESULTS FROM ANY ACT OR FAILURE TO ACT BY HHI, WHETHER NEGLIGENT OR WILLFUL, OR FROM ANY OTHER CAUSE
