The Machining & Welding Cantilever Jib Crane 20 FT Span is a cantilever style jib crane that rotates around a fixed mast, giving you a 20 foot working span and a 4,000 pound working load limit for a dedicated lifting station.

Because the boom swings freely, operators can pull a load away from a machine and set it down nearby in one continuous motion, cutting cycle time compared to a straight-line hoist.

The mast and boom are fabricated from structural steel and designed to rotate smoothly on a bearing or collar assembly, holding the rated capacity through the full range of rotation.

A dedicated jib crane frees up your bridge crane or forklift for other tasks by handling the repetitive lifts at one station on its own.

Facilities ranging from small machine shops to large distribution centers keep equipment like this on hand for the lifts that come up week after week. It is the kind of tool that earns its spot on the floor by saving time on every single pick, and it pays for itself quickly once it replaces improvised rigging on a recurring job.

Before putting any lifting equipment into service, verify it matches your hoist or crane setup and confirm the rated capacity covers your heaviest expected load with margin to spare. Routine inspection of welds, pins, and connection hardware helps catch wear before it becomes a safety issue. Keep a simple inspection log if your facility does not already have one, since tracking wear over time makes it easier to plan replacement before a part actually fails in use.

Durability matters as much as initial capacity when choosing rigging equipment, since hardware that wears unevenly or corrodes quickly ends up costing more over its service life. Choosing components built to recognized manufacturing standards is one of the simplest ways to avoid that added cost down the road.

The specifications below cover everything you need to check compatibility with your equipment.

Order the Machining & Welding Cantilever Jib Crane 20 FT Span and free up your main crane for the jobs that actually need it to travel across the shop.

Product Info:
•  Working Load Limit: 4,000 lbs
•  Boom Span: 20 ft
•  Style: Cantilever, rotating mast
•  Frame Material: Structural steel
•  Shipping Weight: 2305 lbs
