The XA_HA1000CX20 is a rigid PVC extrusion cover formulated for high-amperage Saf_T_Bar C_Series conductor systems (500–1000_A). Spanning 231 inches, it spans multiple rail segments, minimizing joint seams and streamlining installation. Crafted from self-extinguishing PVC with a heat distortion threshold around 160_°F (71_°C), it retains form under clamp pressure and industrial conditions. This cover offers electrical insulation, abrasion protection, and environmental resistance while enabling collectors to maintain consistent tracking without interference
Key Features
High_capacity compatibility — designed for 500–1000_A C_Series systems (e.g., Series_H conductors).
231_in rigid extrusion — covers extensive rail lengths with fewer joints.
Self_extinguishing PVC — safety rated and withstands industrial heat/distortion.
Skin_tight fit — prevents deformation and ensures collector compatibility.
Beige/cream tint — ideal for blending into industrial aesthetics or use as ground/neutral identification.
Technical Specifications
Spec Details
Part Number XA_HA1000CX20
Series Compatibility Saf_T_Bar C_Series (500–1000_A yields, e.g., Series_H)
Material Rigid, self-extinguishing beige PVC
Length 231_in (≈_19_ft_3_in / 5.87_m)
Temp Rating Heat distortion ~160_°F (71_°C) at 260_psi
Function Insulates and protects high_current conductor rails
Applications Overhead cranes, heavy conveyors, monorails, large electrified systems
