The XA_100ACX10W is a white rigid PVC cover extrusion specifically engineered for 90–350_A Saf_T_Bar C_Series conductor rails. The 118_inch length enables extensive coverage with minimal seams and easy installation. Fabricated from self-extinguishing PVC (heat distortion point around 160_°F/71_°C), it delivers excellent electrical insulation, UV resistance, and environmental protection, preventing deformation under clamp pressure and protecting against dust, moisture, abrasion, and UV exposure
. Its skin-tight design ensures smooth collector head tracking and system longevity.
Key Features
Large one-piece length — covers nearly 10 feet of rail, reducing joint seams.
White UV-resistant PVC — for clear identification of phase or neutral circuits and environmental durability.
Self-extinguishing material — rated for industrial safety with high heat resistance
Skin-tight fit — prevents deformation under clamp forces, ensuring consistent collector contact.
Protects from wear — safeguards conductor against dust, moisture, and physical damage.
Technical Specifications
Specification Details
Part Number XA_100ACX10W
Series Compatibility Saf_T_Bar C_Series (90–350_A capacity)
Material Rigid, self_extinguishing white PVC
Extrusion Length 118_in (≈9_ft_10_in / 3.0_m)
Heat Distortion Point ≈160_°F (71_°C) at 260_psi
Function Electrical insulation and mechanical protection for conductor rails
Ideal Applications Overhead cranes, conveyors, monorails, industrial systems
