Harrington ERP Series Electric Chain Hoist with Push Trolley - 1/2 Ton - 10 ft Lift

Write a Review
$3,905.94 - $4,278.69
SKU: ERP005L-10
Condition: New
Availability: Subject to Availability
Weight: 90.00 LBS
Shipping: Calculated at Checkout
product: Electric Chain Hoist, 1,000 lb, Push Trolley
Color: Yellow
Hoist Mount: Push Trolley
Includes: Chain Container, Push Trolley
Lift Speed: 7 fpm
Housing Width: 13 in
Manufacturers Warranty Length: 1 yr
Housing Length: 22 1/4 in
Housing Depth: 6 5/8 in
Minimum Retracted Length: 15 13/32 in
Minimum Radius Curve: 43 5/16 in
For Maximum Beam Height: Not Applicable
Trolley Wheel Diameter: 3 1/5 in
Lifting Hook Opening Width: 29/32 in
Maximum Lifting Length: 15 ft
Controller Cord Length: 11 ft
For Max Beam Flange Width: 5 in
Body Depth: 6 5/8 in
Body Length: 22 1/4 in
For Minimum Beam Height: 3 3/16 in
Body Width: 13 in
For Min Beam Flange Width: 2 1/4 in
Electric Hoist Item: Chain Hoist
Load Capacity: 1,000 - 2,499 lbs
Min Between Hooks: 14 5/8 in
Motor HP: 0.375 hp
Phase: 1
Standards: ANSI/ASME B30.16, ASME HST-1M
Fits Brand: Harrington Hoists Inc
Lubrication: Oil Bath
Control Cord: 11 ft
Reeving: 1
Clutch: Friction Clutch
Trolley Configuration: Push Trolley
Thermal Protection: Option
Amps @ Low Volts: 7.7 A
Brake: Pull-Rotor
Finish: Electrostatic Enamel
Number of Speeds: 1
Fits Beam Flange W: 2-1/4 in to 5 in
Classification: H4
Control: Push Button Pendant
Item: Electric Chain Hoist
Trolley Speed: Not Applicable
Features: Extreme-Duty, Fan-Cooled Motor, Heavy Cast-Iron Chain Guide, Friction Clutch, Oil Bath-Lubricated, Heat-Treated Gearing, Self-Adjusting Maintenance-Free Brake
Material: Die Cast Aluminum
Trolley Wheel Material: Steel
Chain Finish: Nickel Plated
Body Finish: Enamel
Duty Classification: H4
Controls: Push Button Pendant
Motor Horsepower: 3/8 hp
Includes Clutch: Clutch Included
Maximum Lifting Capacity: 1,000 lb
Suspension / Mounting: Plain (Push) Trolley
Speed: Single Speed
Capacity: 1,000 - 2,499 lbs
Lift: 15 ft
Voltage: 230/1/60
Adding to cart… The item has been added
Harrington ERP Series Electric Chain Hoist with Push Trolley - 1/2 Ton - 10 ft Lift

Harrington ERP Series Electric Chain Hoist with Push Trolley - 1/2 Ton - 10 ft Lift

$3,905.94 - $4,278.69

Harrington ERP Series Electric Chain Hoist with Push Trolley - 1/2 Ton - 10 ft Lift

$3,905.94 - $4,278.69

The ERP005L HARRINGTON ERP Electric Chain Hoist with Push Trolley is a reliable and powerful tool that will make transporting heavy loads a breeze. With a lifting capacity ranging from 1/2 Tons, this hoist is perfect for small workshops and infrequent moves. Whether you need to lift heavy equipment or move materials from one location to another, this hoist will get the job done efficiently and safely.The NER/ER Series hoist, when mounted on the PT push trolley, creates an economical and efficient solution for all your transportation needs. The push trolley allows for smooth and controlled movement, ensuring that your loads are transported safely and securely.Investing in the ERP005L HARRINGTON ERP Electric Chain Hoist with Push Trolley will save you time and energy. Instead of struggling to move heavy loads manually or with less powerful hoists, this hoist will do all the heavy lifting for you. You can trust in the reliability and durability of this hoist to perform consistently and effectively, even in demanding work environments.Whether you're working in a workshop, warehouse, or construction site, this hoist will be a valuable addition to your equipment. It is designed to withstand heavy use and deliver reliable performance, giving you peace of mind knowing that you can rely on it to get the job done.Make your work environment more efficient and productive with the ERP005L HARRINGTON ERP Electric Chain Hoist with Push Trolley. Experience the difference it can make in your daily tasks and invest in this reliable and powerful hoist today.

All products sold by Harrington Hoists, Inc. (HHI) are warranted to be free from defects in material and workmanship from the date of shipment, with coverage periods varying by product type - 1 year for electric and air powered hoists (excluding (N)ER2 and EQ/SEQ hoists), powered trolleys, powered Tiger Track jibs and gantries, crane components, below-the-hook devices, and spare/replacement parts; 2 years for manual hoists and trolleys and beam clamps; 3 years for (N)ER2 hoists, EQ/SEQ hoists, (T)EM/(T)SEM hoists, and RY hoists; 5 years for manual Tiger Track jibs and gantries and hoist motor brakes for EQ/SEQ, (T)EM/(T)SEM, and RY; and 10 years for the (N)ER2 brake and TNER hoist motor brake - provided the buyer notifies HHI in writing within sixty (60) days of discovering any alleged defect and the product has been used according to manufacturer recommendations without abuse, lack of maintenance, misuse, negligence, or unauthorized repairs or alterations. If HHI's inspection confirms a defect in material or workmanship within the applicable warranty period, HHI will, at its discretion, repair or replace the part or product free of charge (not including installation), with delivery made F.O.B. HHI's place of business for U.S. customers or FCA HHI's U.S. location for international customers under Incoterms 2010; no warranty claim will be honored without valid proof of purchase, the customer must obtain a Return Goods Authorization before shipping the product freight-prepaid along with an explanation of the complaint, repaired products remain covered for the rest of the original warranty period, replacement parts installed after the original warranty period carry only a one-year replacement warranty (not including installation) from installation, and if no defect is found or the defect falls outside the warranty's scope, the customer is responsible for return shipping costs. HHI disclaims all other express or implied warranties, including merchantability or fitness for a particular purpose, and will not be liable for death, personal injury, property damage, or incidental, contingent, special, or consequential damages, losses, or expenses arising from the use or misuse of its products, regardless of whether such damage results from any act or failure to act by HHI, whether negligent, willful, or otherwise.
