The XA_HB2C_250T_30_LATL is a 250 Amp collector designed for use with Hevi-Bar II conductor bar systems, featuring a Jointed Heavy-Duty (J-HD) TDM arm with a lateral mount configuration and 30.00 inches of travel. This collector is specifically engineered for mobile power transfer systems requiring significant lateral movement and flexibility, making it ideal for overhead cranes, automated material handling systems, and other applications where space is limited and reliable electrical contact is essential.
The lateral mount design allows for efficient installation and optimal positioning in tight spaces, while the TDM arm provides flexibility to handle variations in track alignment or positional changes. The 30-inch travel enables the collector to handle a wider range of motion, accommodating longer spans or systems with more dynamic motion profiles.
With its 250A current rating, this collector is capable of supporting medium to high power applications, ensuring reliable power transfer over extended distances, even under heavy-duty conditions.
Key Features
250 Amp Rating – Suitable for medium-to-heavy duty mobile power applications.
Jointed Heavy-Duty TDM Arm – Provides flexibility and smooth movement, even in misaligned systems.
Lateral Mount Configuration – Ideal for side-entry installation in constrained or tight spaces.
30.00" Travel – Accommodates larger lateral movements for extended track configurations.
Reliable Electrical Contact – Ensures consistent and stable power transfer across the full range of motion.
Durable Construction – Built to withstand the rigors of high-duty-cycle operations.
Perfect for Cranes, Gantries, and Automated Systems – Handles demanding electrification systems that require mobility and flexibility.
Designed for Hevi-Bar II Systems – Compatible with 500A–1500A conductor bars.
