The XA_HB2C_250T_21_LATL_RAD is a 250 Amp collector assembly designed for use with Hevi-Bar II conductor systems. This model features a Jointed Heavy-Duty (J-HD) TDM-style arm, optimized for lateral mounting and offering extended travel in applications requiring high flexibility and adaptability. The radiused design is ideal for systems where the conductor bar path features curves or angled sections, such as crane tracks, gantries, and automated material handling systems.
With 21.00 inches of travel and the lateral mount configuration, this collector ensures stable and reliable electrical contact even under significant movement or structural misalignment. The radiused design enhances the collector’s ability to handle curves, helping to maintain continuous, stable power transfer without compromising the performance of the system.
Built for demanding environments, the J-HD TDM arm configuration ensures a smooth, consistent connection between the moving equipment and the conductor bar system. It is engineered for medium to high-power applications and can handle 250A of current with ease, providing long-lasting performance in high-duty-cycle operations.
Key Features
250 Amp Current Rating – Suitable for medium to heavy-duty electrification needs.
Jointed Heavy-Duty TDM Arm – Provides superior flexibility, even in curved or angled tracks.
Lateral Mount Configuration – Designed for side-entry and lateral installation in tight or constrained spaces.
Radiused Design – Allows smooth operation over curved conductor bar paths.
Extended 21.00" Travel – Accommodates larger lateral movement for more extensive track systems.
Reliable Electrical Contact – Maintains stable power transfer during dynamic motion.
Durable Construction – Built for high-cycle industrial applications with minimal maintenance.
Ideal for Cranes, Gantries, and Automated Systems – Excellent in high-flex, long-distance mobile electrification setups.
Designed for Hevi-Bar II Systems – Compatible with 500A to 1500A bars.
