The XA_HB2C_250T_42 is a 250 Amp collector assembly designed for Hevi-Bar II conductor systems, featuring a Jointed Heavy-Duty (J-HD) TDM-style arm with an extended 42.00-inch Pre-Gathered Travel (PGT). This collector is ideal for industrial applications requiring significant lateral reach and movement flexibility, such as long-span bridge cranes, automated storage and retrieval systems (AS/RS), and mobile electrification equipment operating under variable alignment.
With its jointed arm configuration, the collector delivers enhanced articulation and adaptability, allowing it to maintain consistent shoe-to-bar contact even in systems with structural variation or bar misalignment. The TDM (Tracked Dual Mount) design ensures smooth motion and steady pressure across the full range of travel, minimizing mechanical stress and contact wear.
Rated at 250A, this collector provides reliable power delivery for medium-to-high current loads in environments where mobility and endurance are critical. Its rugged construction and extended PGT capacity make it a dependable choice for high-performance electrified rail systems.
Key Features
250A Current Rating – Suitable for mid-to-heavy duty power transfer applications.
42.00" Pre-Gathered Travel (PGT) – Supports large-scale lateral movement and tracking flexibility.
Jointed Heavy-Duty (J-HD) TDM Arm – Provides improved flexibility and alignment tolerance.
Optimized for Hevi-Bar II Systems – Integrates with conductor bars from 500A to 1500A.
Consistent Electrical Contact – Ensures power stability during full motion range.
Durable and Corrosion-Resistant – Designed for long-term industrial performance.
Ideal for Cranes, Gantries, and AS/RS Systems – Performs well in continuous-duty applications.
Low Maintenance Design – Built to reduce wear and service downtime.
