Product Overview
Bishamon LX-200WL – Extra-Wide Manual Scissor Lift Table (4,400 lb Capacity, Long Platform)
Lift Heavy. Lift Wide. Lift Smart.
The Bishamon LX-200WL is a heavy-duty manual scissor lift table designed for lifting and positioning extra-wide, oversized loads in demanding industrial environments. With a 4,400 lb (2,000 kg) capacity and an extended platform length and width, the LX-200WL is ideal for handling large components, pallets, or tooling where added support and stability are essential.
This model features a foot-operated hydraulic pump for smooth lifting and a hand-controlled lowering valve for precise positioning. With a welded steel frame, protected by a durable powder coat finish, ensuring long-lasting performance. Heavy-duty polyurethane casters allow for safe and controlled movement across shop floors, with two swivel wheels with brakes and two rigid wheels for enhanced stability.
Whether you're in manufacturing, fabrication, or warehouse environments, the LX-200WL enhances workplace ergonomics and productivity by eliminating the need to bend, strain, or overreach.
Key Features
- Ultra-Strong Load Capacity – Handles loads up to 4,400 lbs (2,000 kg)
- Extra-Wide and Long Platform – Ideal for larger items and wider load distribution
- Effortless Manual Operation – Foot pump lift and hand lever release
- Safe and Mobile – Industrial-grade wheels and brake system
- Heavy-Duty Construction – Steel frame and scissor arms built for daily industrial use
Common Applications
- Machine shops and fabrication plants
- Heavy-duty packaging and assembly lines
- Automotive and aerospace production
- Industrial maintenance facilities
Technical Specifications – Bishamon LX-200WL
SpecificationDetails
Model LX-200WL
Load Capacity 4,400 lbs (2,000 kg)
Lift Mechanism Manual hydraulic (foot pump)
Platform Dimensions Approx. 48" L x 30" W (extra-long/wide)
Lowered Height Approx. 15 inches
Raised Height Approx. 39 inches
Lift Control Foot pump lift, hand lever lowering
Wheel Type Polyurethane
Wheel Configuration 2 swivel w/ brakes, 2 rigid
Construction Welded steel with powder-coated finish
Color Bishamon Blue
