The XA_34249, part of Conductix_Wampfler’s 80_Series 10-button pendants, is engineered for complex industrial control environments. It includes:
8 _ three-speed maintained selector switches — each offering spring_return positions for precise low/medium/high speed control
1 _ maintained on/off switch pair, providing robust power control with latch positions
All controls are mounted in a heavy-duty, two-piece yellow ABS enclosure, fully sealed to NEMA_4X/IP65 standards and UL/cUL-listed for indoor use. The pendant features silicone-booted buttons, a stepped cable bushing fitting Ø_7.5–29.5_mm cable, and an integrated S-hook strain relief for durability and simplified installation. It weighs approximately 2.09_lb, balancing high functionality with ergonomic design.
This pendant is ideal for controlling overhead cranes, conveyors, hoists, and other industrial systems requiring extensive multi-speed maintained control in a sealed, operator-friendly package. Conductix_Wampfler also offers optional pre-assembly and pre-wiring services when purchased with a pendant cable.
Key Features & Specifications
Feature Specification
Button Configuration 8 _ three-speed maintained switches
1 _ maintained on/off pair
Enclosure High-impact yellow ABS; UL/cUL-listed; sealed NEMA_4X/IP65
Cable Strain Relief Stepped bushing (Ø_7.5–29.5_mm) with S-hook
Weight Approx. 2.09_lb
Assembly Options Factory-assembled; pre-wiring available with pendant cable
