NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 10 Tons NERP100S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Enhance your lifting capabilities with the NERP100S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley. This exceptional hoist is engineered to effortlessly transport heavy loads, providing a lifting capacity ranging from 10 Tons . With its impressive 15 feet lift, this hoist is the ultimate choice for small workshops and occasional moves.The NERP100S Electric Chain Hoist, when combined with the PT push trolley, delivers unparalleled maneuverability and reliable performance. Whether you need to transport materials or equipment, this hoist guarantees a smooth and efficient operation. Its convenience and affordability make it an indispensable tool for businesses seeking to streamline their lifting process.Immerse yourself in the difference that this reliable and versatile hoist can make in your workflow. The NERP100S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley empowers you to effortlessly tackle heavy loads. Uplift your equipment today and savor effortless heavy-load transport like never before. Acquire the NERP100S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley and elevate your lifting capabilities to new heights.

Product Specifications

.

Part Number:

NERP100S-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 20,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

11 fpm

Housing Width:

13 1/4 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

28 7/8 in

For Minimum Beam Flange Width:

5 1/2 in

For Maximum Beam Flange Width:

8 21/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 1/4 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

7 5/16 in

Body Length:

28 7/8 in

Minimum Radius Curve:

118 3/32 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

7 3/10 in

Lifting Hook Opening Width:

3 3/16 in

Minimum Retracted Length:

46 1/2 in

Load Capacity:

20,000 lb

Minimum Between Hooks:

46 1/2 in

Motor HP:

4.7 hp x2

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Item:

Electric Chain Hoist

Reeving:

4

Thermal Protection:

Yes

Brake:

Electromagnetic

Control Cord:

11 ft

Amps @ Low Volts:

16.4x2

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

11 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

4

Motor Horsepower:

4 3/4 hp

Headroom:

46 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

20,000 lb

Current at Minimum Voltage:

32.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

15.8 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
