NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 5 Tons, NERP050L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your workshop with the powerful NERP050L-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley. This top-of-the-line hoist is the ultimate solution for effortlessly moving heavy loads in your small workshop. Boasting Capacity 5 Tons, and a 15-foot lift, this electric chain hoist ensures reliable performance and efficient lifting every time.With its innovative push trolley design, you can easily maneuver your loads with minimal effort, saving you valuable time and energy. No more straining or struggling to lift heavy objects ‚ the NERP050L-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley does the hard work for you.Built to withstand the toughest working conditions, this hoist is sturdy, durable, and built to last. The high-quality construction ensures that your hoist will remain reliable for years to come, providing you with peace of mind and confidence in your workshop.Don't settle for less when it comes to your lifting needs. Invest in the NERP050L-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley and experience the convenience and efficiency it brings to your workflow. Whether you're lifting heavy machinery, equipment, or materials, this hoist will make the job easier and more efficient.Say goodbye to manual labor and hello to effortless lifting with the NERP050L-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley. Its user-friendly design ensures that anyone can operate it with ease. No special training or expertise required.Order yours today and revolutionize your workshop. With the NERP050L-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley, you can increase productivity, save time, and reduce the risk of injuries caused by lifting heavy loads. Upgrade your workshop and experience the convenience and efficiency of this top-of-the-line hoist.

Product Specifications

.

Part Number:

NERP050L-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 10,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

11 fpm

Housing Width:

17 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

10 1/2 in

Housing Length:

28 7/8 in

For Minimum Beam Flange Width:

4 in

For Maximum Beam Flange Width:

7 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

17 1/2 in

Body Depth:

10 1/2 in

For Minimum Beam Height:

6 11/16 in

Body Length:

28 7/8 in

Minimum Radius Curve:

90 19/32 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

6 7/10 in

Lifting Hook Opening Width:

1 29/32 in

Minimum Retracted Length:

33 3/32 in

Load Capacity:

10,000 lb

Minimum Between Hooks:

35 3/8 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control:

11 ft

Control Cord:

11 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

11 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

35 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

10,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
