NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 3 Tons, NERP030C Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP030C-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley is an essential tool for enhancing the efficiency of your workshop. Designed to withstand daily use in a workshop setting, this electric chain hoist offers exceptional performance and convenience.With its sturdy construction, this hoist is built to handle the rigors of heavy lifting. It can lift Capacity 3 Tons, making it suitable for a variety of applications in your workshop.The NERP030C-15 features a 15-foot lift, providing ample reach for moving heavy loads with precision and safety. This generous lift height allows you to efficiently transport materials or lift equipment to the desired height, saving you time and effort.Equipped with a push trolley, this hoist offers added convenience. The push trolley allows for easy movement along the beam, providing flexibility in positioning and transporting heavy loads. With smooth and steady movement, navigating your workshop becomes a breeze.Not only does this hoist and trolley combination offer impressive performance, but it also guarantees unbeatable reliability. Built to withstand tough conditions, it will consistently deliver outstanding results. With its robust construction and high-quality components, you can trust the NERP030C-15 to meet all your workshop needs.Upgrade your workshop efficiency with the NERP030C-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley. This reliable and durable hoist and trolley combination ensures safe and precise load transportation, allowing you to complete your tasks with ease. Experience unparalleled performance and convenience with this exceptional product.

Product Specifications

.

Part Number:

NERP030C-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 6,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

17 fpm

Housing Width:

16 13/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

9 1/2 in

Housing Length:

27 5/8 in

For Minimum Beam Flange Width:

3 1/4 in

For Maximum Beam Flange Width:

6 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 13/16 in

Body Depth:

9 1/2 in

For Minimum Beam Height:

5 13/16 in

Body Length:

27 5/8 in

Minimum Radius Curve:

66 29/32 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

5 4/5 in

Lifting Hook Opening Width:

1 13/16 in

Minimum Retracted Length:

32 11/16 in

Load Capacity:

6,000 lb

Minimum Between Hooks:

32 11/16 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

2

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

17 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

2

Motor Horsepower:

4 3/4 hp

Headroom:

32 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

6,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
