NERP Electric Chain Hoist with Push Trolley 15' Lift-Capacity 2 Tons, NERP020S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your workshop with the NERP020S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley. This high-quality hoist is designed to provide convenience, durability, and affordability, making it the perfect addition to small workshops and for occasional moves. The NERP020S Electric Chain Hoist with Push Trolley offers easy transportation of heavy loads with its 15' lift and is capable of handling Capacity ranging from 2 Tons, Designed for reliability and simplicity, this electric chain hoist is a must-have for any workshop owner or professional. With its efficient performance, you can effortlessly transport materials, increasing productivity and reducing strain on workers. The NERP020S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley is built to last. Its robust construction ensures durability and long-lasting performance, even under demanding conditions. The high-quality materials used in its manufacturing guarantee that it can withstand heavy use and repetitive lifting tasks. This hoist is not only powerful but also easy to operate. Its ergonomic design allows for easy handling and maneuvering, ensuring smooth and precise movements. The push trolley feature provides added flexibility, allowing you to move loads horizontally along the workshop floor effortlessly. With the NERP020S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley, load transportation becomes a breeze. Whether you need to move heavy machinery, equipment, or materials, this hoist will make the task easier and more efficient. Investing in this electric chain hoist will save you time and effort while enhancing overall workplace safety. Its reliable performance and user-friendly design make it an essential tool for any workshop or professional setting. Say goodbye to manual lifting and strain, and say hello to hassle-free load transportation. Upgrade your workshop today with the NERP020S-15 HARRINGTON NERP Electric Chain Hoist with Push Trolley, and experience the ease and convenience it brings to your work environment.

Product Specifications

.

Part Number:

NERP020S-15

Color:

Yellow

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 4,000 lb, 15 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

28 fpm

Housing Width:

16 13/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

9 1/2 in

Housing Length:

27 5/8 in

For Minimum Beam Flange Width:

3 1/4 in

For Maximum Beam Flange Width:

6 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 13/16 in

Body Depth:

9 1/2 in

For Minimum Beam Height:

5 in

Body Length:

27 5/8 in

Minimum Radius Curve:

59 3/32 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

5 in

Lifting Hook Opening Width:

1 19/32 in

Minimum Retracted Length:

25 19/32 in

Load Capacity:

4,000 lb

Minimum Between Hooks:

25 5/8 in

Motor HP:

4.7 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Finish:

Electrostatic Enamel

Amps @ Low Volts:

16.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

28 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

4 3/4 hp

Headroom:

25 19/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

4,000 lb

Current at Minimum Voltage:

16.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

7.9 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
