NERP Electric Chain Hoist with Push Trolley 10' Lift-Capacity 2 Tons NERP020L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP020L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is a versatile and efficient solution for transporting heavy loads. Whether you need to move equipment in a small workshop or complete infrequent moves, this hoist and trolley combination provides an economical and reliable option.With a lifting capacity ranging from 2 Tons, this electric chain hoist is capable of handling a wide range of loads. No matter the size or weight of your load, this hoist has the power you need to tackle any job with ease. Say goodbye to manual lifting and save your energy for more important tasks.The push trolley feature of this hoist allows for smooth and effortless movement of your load. With minimal effort, you can easily position and transport heavy items, ensuring convenience and ease of use. The trolley system also adds a level of stability and control, providing additional safety during operation.As with all Harrington products, the NERP020L-10 is known for its reliability and performance. You can trust that this electric chain hoist will withstand the demands of your work environment and deliver consistent results. Upgrade your lifting equipment today and experience the difference in your workflow.Whether you're handling small loads or heavier industrial applications, the NERP020L-10 HARRINGTON NERP Electric Chain Hoist with Push Trolley is the perfect choice. Its durability, flexibility, and efficiency make it an indispensable tool in any setting. Don't let heavy loads slow you down-invest in the NERP020L-10 and get the job done with ease.

Product Specifications

.

Part Number:

NERP020L-10

Color:

Yellow

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 4,000 lb, 10 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

14 fpm

Housing Width:

16 13/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

9 1/2 in

Housing Length:

25 3/8 in

For Minimum Beam Flange Width:

3 1/4 in

For Maximum Beam Flange Width:

6 1/32 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

16 13/16 in

Body Depth:

9 1/2 in

For Minimum Beam Height:

5 in

Body Length:

25 3/8 in

Minimum Radius Curve:

59 3/32 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

5 in

Lifting Hook Opening Width:

1 19/32 in

Minimum Retracted Length:

25 in

Load Capacity:

4,000 lb

Minimum Between Hooks:

25 in

Motor HP:

2.4 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

8.6 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

2 3/8 hp

Headroom:

25 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

4,000 lb

Current at Minimum Voltage:

8.6 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

4.2 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
