NERP-FG Electric Food Grade Chain Hoist with Push Trolley 10' Lift-Capacity 1 Tons NERP010L-FG Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP010L-FG-10 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley is the perfect addition to any food processing or packaging operation. This electric hoist is specifically designed for food-grade applications, ensuring the utmost safety and efficiency in your lifting processes.With a lift capacity of 10', this hoist is capable of handling a range of 1 Tons , allowing you to handle a variety of loads with ease. The food-grade chain and push trolley of this hoist guarantee that no contaminants will come into contact with your goods, ensuring the highest levels of hygiene and ensuring compliance with food safety regulations.Constructed with durability and reliability in mind, this electric hoist is built to withstand the demands of heavy-duty food-processing environments. It is designed to provide long-lasting performance, reducing the risk of downtime and the need for frequent repairs or replacements. This means you can focus on your food production processes without worrying about equipment failures.Investing in the NERP010L-FG-10 HARRINGTON NERP-FG Electric Food Grade Chain Hoist is an investment in your productivity and peace of mind. By upgrading your food processing equipment with this high-quality hoist, you can streamline your operations, increase efficiency, and improve overall productivity. You can trust that this hoist will consistently perform at its best, ensuring smooth and effective lifting processes.Revolutionize your food production processes with the NERP010L-FG-10 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley. Whether you are in the food processing or packaging industry, this hoist is the ideal solution to enhance your lifting capabilities. Experience the benefits of optimized productivity and the assurance of safe and efficient operations by investing in this top-of-the-line electric hoist. Take your food processing operations to the next level with the NERP010L-FG-10 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley.

Product Specifications

.

Part Number:

NERP010L-FG-10

Color:

White

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 2,000 lb, 10 ft, Push Trolley, White=Hoist Mount=Push Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

14 fpm

Housing Width:

9 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

18 1/2 in

Housing Length:

24 1/8 in

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

5 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

9 11/16 in

Body Depth:

18 1/2 in

For Minimum Beam Height:

4 3/16 in

Body Length:

24 1/8 in

Minimum Radius Curve:

51 3/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

2 13/16 in

Lifting Hook Opening Width:

18 1/2 in

Minimum Retracted Length:

18 1/2 in

Load Capacity:

2,000 lb

Minimum Between Hooks:

18 1/2 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control:

110V Push Button Control Pendant

Control Cord:

6 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

FDA Approved Food-Safe Oil, Grease and Lubricants

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

14 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

18 1/2 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

2,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.5 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
