NERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1/2 Tons NERP005S Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP Electric Chain Hoist with Push Trolley, model NERP005S-20, is engineered for superior performance and reliability, making it an exceptional choice for any heavy lifting requirement. With a lifting capacity of 1/2 tons, this hoist adeptly manages loads in various environments, from compact workshops to expansive industrial settings, ensuring efficiency and productivity during every task.

One of the standout features of the NERP005S is its integrated push trolley, which facilitates effortless maneuverability, allowing operators to navigate challenging spaces with precision. The ergonomic design promotes user-friendly operation while enhancing safety, so you can focus on the job at hand knowing that your load will be transported securely, minimizing the risk of spills or accidents.

With a generous 20-foot lift height, this electric chain hoist is remarkably versatile. It accommodates a broad spectrum of lifting tasks, making it an indispensable tool across multiple applications, including construction sites and warehouses. Its compact design ensures that it can be easily installed in areas with limited space, optimizing your workflow without compromising on power or performance.

Built to meet the highest standards of quality, the NERP005S-20 features durable materials crafted for longevity. This hoist is designed to withstand the rigors of daily use, promising a dependable solution for your lifting needs over the long term.

Investing in the NERP Electric Chain Hoist with Push Trolley not only streamlines your heavy load transportation but also enhances overall work efficiency. Experience the exceptional performance, seamless movement, and superior lifting capability of this hoist to revolutionize your operational approach. Whether handling heavy machinery or building materials, the NERP005S-20 is the ultimate tool for simplifying your lifting tasks with ease.

Product Specifications

.

Part Number:

NERP005S-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 1,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

29 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

4 3/16 in

Body Length:

20 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

17 1/8 in

Motor HP:

1.2 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Clutch:

Friction Clutch

Reeving:

1

Thermal Protection:

Yes

Control:

16 ft

Control Cord:

16 ft

Amps @ Low Volts:

4.8 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Material:

Die Cast Aluminum

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

29 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

1 1/4 hp

Headroom:

17 3/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

4.8 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

2.5 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
