NERP-FG Electric Food Grade Chain Hoist with Push Trolley 15' Lift-Capacity 1/2 Tons NERP005L-FG Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your food processing or packaging operations with the NERP005L-FG-15 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley. This high-quality electric chain hoist is designed to meet food-grade standards, ensuring the safety and integrity of your food products.With a lift capacity of up to 1/2 Tons this hoist provides efficient lifting and movement of your goods. The push trolley allows for easy maneuverability, making it a convenient choice for your food-related business. Whether you are lifting heavy containers or transporting ingredients, this hoist will streamline your operations and increase productivity.The NERP005L-FG Electric Chain Hoist is constructed with durability in mind. Its reliable performance and sturdy design make it suitable for heavy-duty use in demanding environments. You can trust this hoist to withstand the rigors of your food processing or packaging facility, providing you with long-lasting performance.Not only is this hoist functional, but it also meets the highest hygiene standards. Its food-grade construction ensures that your food products remain uncontaminated during the lifting and transport process. When it comes to the safety and quality of your goods, this hoist is a smart investment.Shop now and bring the convenience and productivity of the NERP005L-FG-15 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley to your operation. With its impressive lift capacity, durable construction, and food-grade design, this hoist is sure to enhance the efficiency of your food processing or packaging facility. Upgrade your equipment today and experience the benefits of this reliable and high-performance hoist.

Product Specifications

.

Part Number:

NERP005L-FG-15

Color:

White

Hoist Lift:

15 ft

Product:

Electric Chain Hoist, 1,000 lb, 15 ft, Push Trolley, White=Hoist Mount=Push Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

15 fpm

Housing Width:

8 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

16 5/16 in

Housing Length:

22 3/8 in

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

8 1/2 in

Body Depth:

16 5/16 in

For Minimum Beam Height:

3 3/16 in

Body Length:

22 3/8 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

15 ft

Controller Cord Length:

11 ft

Trolley Wheel Diameter:

2 23/64 in

Lifting Hook Opening Width:

16 5/16 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

11 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

FDA Approved Food-Safe Oil, Grease and Lubricants

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
