NERP-FG Electric Food Grade Chain Hoist with Push Trolley 10' Lift-Capacity 1/2 Tons NERP005L-FG Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

Upgrade your food processing or packaging applications with the NERP005L-FG-10 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley. This electric hoist is designed specifically for the stringent requirements of the food industry, ensuring safe and efficient lifting of loads up 1/2 Tons .With a lift capacity of 10 ft, this hoist allows you to easily maneuver goods within your facility, improving overall productivity. The NERP005L-FG-10 features a durable, food-grade construction that meets the highest hygiene standards, ensuring the safety and integrity of your food products.The push trolley of this hoist allows for easy movement and positioning of loads, saving you time and effort. You can trust the NERP005L-FG-10 to efficiently handle and transport your goods without compromising on food-grade compliance.This electric hoist is the perfect addition to any food processing or packaging operation. With its dependable performance and food-grade construction, you can trust it to meet your lifting needs while adhering to the strict regulations of the food industry.Upgrade to the NERP005L-FG-10 Electric Chain Hoist with Push Trolley and experience the benefits of enhanced productivity and food-grade compliance. This hoist is designed to withstand the harsh conditions of the food industry, ensuring long-lasting performance and reliability.Whether you need to lift heavy loads or transport goods within your facility, the NERP005L-FG-10 is the ideal solution. Invest in this electric hoist and enjoy the peace of mind that comes with knowing your lifting equipment meets the highest safety and hygiene standards. Upgrade your food processing or packaging operations today with the NERP005L-FG-10 HARRINGTON NERP-FG Electric Food Grade Chain Hoist with Push Trolley.

Product Specifications

.

Part Number:

NERP005L-FG-10

Color:

White

Hoist Lift:

10 ft

Product:

Electric Chain Hoist, 1,000 lb, 10 ft, Push Trolley, White=Hoist Mount=Push Trolley

Includes:

Chain Container, Quick Disconnect Plugs On Pendant and Power Cord

Lift Speed:

15 fpm

Housing Width:

8 1/2 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

16 5/16 in

Housing Length:

22 3/8 in

For Minimum Beam Flange Width:

2 9/32 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

8 1/2 in

Body Depth:

16 5/16 in

For Minimum Beam Height:

3 3/16 in

Body Length:

22 3/8 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

10 ft

Controller Cord Length:

6 ft

Trolley Wheel Diameter:

2 23/64 in

Lifting Hook Opening Width:

16 5/16 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

16 5/16 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ANSI/ASME HST-1M, ANSI/NFPA 70

Voltage:

230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Food Grade Oil

Reeving:

1

Thermal Protection:

Yes

Control Cord:

6 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

FDA Approved Food-Safe Oil, Grease and Lubricants

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

16 5/16 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Epoxy Painted

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
