NERP Electric Chain Hoist with Push Trolley 20' Lift-Capacity 1/2 Tons NERP005L Electric Chain Hoist with Push Trolley HARRINGTON

Product Overview

The NERP005L-20 HARRINGTON Electric Chain Hoist with Push Trolley is an essential tool for any workshop aiming to streamline operations and enhance productivity. Designed with a remarkable 20-foot lift capacity and a robust 1/2-ton lift capability, this hoist is engineered to tackle even the heaviest loads with absolute ease.

Combining the power of an electric chain hoist with the versatility of a push trolley, the NERP005L-20 significantly reduces the physical strain associated with heavy lifting and transport tasks. Its compact design makes it especially suitable for smaller workshops or for occasional heavy lifting needs, allowing for efficient and practical storage without sacrificing performance.

Reliability and durability are hallmarks of the NERP005L-20. Constructed for durability, this hoist can withstand the rigors of demanding work environments, ensuring that you’re equipped to handle tasks without interruptions. Say goodbye to the inefficiencies of manual handling and labor-intensive processes; this electric hoist simplifies your workload, allowing you to concentrate on the core aspects of your projects.

Perfect for professionals across various fields, the NERP005L-20 enables seamless movement of heavy materials and equipment. It enhances workflow and minimizes downtime, making it an indispensable asset in every workspace.

Investing in the NERP005L-20 HARRINGTON Electric Chain Hoist with Push Trolley means choosing a reliable solution that offers both efficiency and ease of use. Elevate your workshop operations, reduce the risk of injury, and experience a new standard of productivity. This high-performance hoist and trolley combination isn’t just an upgrade; it’s a strategic investment in the future of work efficiency. Discover the capabilities of the NERP005L-20 today and transform your approach to heavy lifting.

Product Specifications

.

Part Number:

NERP005L-20

Color:

Yellow

Hoist Lift:

20 ft

Product:

Electric Chain Hoist, 1,000 lb, 20 ft, Push Trolley=Hoist Mount=Push Trolley

Includes:

10 Year Brake Warranty, Chain Container, Push Trolley, Quick Disconnect Plugs On Pendant And Power Cords

Lift Speed:

15 fpm

Housing Width:

13 11/16 in

Manufacturers Warranty Length:

10 yr Brake Warranty, 3 yr

Housing Depth:

7 1/2 in

Housing Length:

20 1/4 in

For Minimum Beam Flange Width:

2 1/4 in

For Maximum Beam Flange Width:

4 in

For Maximum Beam Height:

Not Applicable

MFR Warranty Length:

1 yr

Body Width:

13 11/16 in

Body Depth:

7 1/2 in

For Minimum Beam Height:

4 3/16 in

Body Length:

20 1/4 in

Minimum Radius Curve:

43 5/16 in

Maximum Lifting Length:

20 ft

Controller Cord Length:

16 ft

Trolley Wheel Diameter:

3 1/5 in

Lifting Hook Opening Width:

1 3/32 in

Minimum Retracted Length:

16 5/16 in

Load Capacity:

1,000 lb

Minimum Between Hooks:

17 1/8 in

Motor HP:

0.75 hp

Phase:

3

Standards:

ANSI/ASME B30.16, ASME HST-1M, NFPA 70, RoHS Compliant, UL 1340

Voltage:

208/230/460V

Fits Brand:

Harrington Hoists Inc

Lubrication:

Oil Bath

Item:

Electric Chain Hoist

Reeving:

1

Thermal Protection:

Yes

Control Cord:

16 ft

Amps @ Low Volts:

3.4 A

Number of Speeds:

1

Trolley Configuration:

Push Trolley

Trolley Speed:

Not Applicable

Features:

Count Hour Meter, Extreme Duty Motor, Push Trolley, Smart Brake Technology

Lifting Hook Material:

Carbon Steel

Includes Clutch:

Clutch Included

Overload Protection Included:

Yes

Brake Type:

DC Current

Chain Grade:

Grade 80

Maximum Lift Speed:

Not Applicable

Included Components:

Chain Container, Pendant, Quick Disconnect Plugs on Pendant, Safety Latch Hook

Fixed Lift Speed:

15 fpm

Clutch Type:

Friction Clutch

Minimum Lift Speed:

Not Applicable

Pendant IP Rating:

IP65

Chain Finish:

Nickel Plated

Controls:

Push Button Pendant=Mount Type=Push Trolley

Starts and Stops per Hour:

360

Duty Classification:

H4

Maximum Pulling Capacity:

Not Applicable

Number of Reeves:

1

Motor Horsepower:

3/4 hp

Headroom:

17 3/32 in

Includes Brake:

Brake Included

For Outdoor Use:

Yes

Hoist IP Rating:

IP55

Lifting Hook Type:

Swivel Hook with Safety Latch

Maximum Lifting Capacity:

1,000 lb

Current at Minimum Voltage:

3.4 A

Trolley Wheel Material:

Steel

Current at Maximum Voltage:

1.7 A

Body Finish:

Enamel

Number of Load Chains:

1

Body Material:

Aluminum

Trolley IP Rating:

Not Applicable

Programmable:

Non-Programmable
